Austin Hughes IPM-03 - Manual (Page 44)

www.austin-hughes.com UM-IPM-03-Q214V3 P.39
Part VI. SNMP Setup / Firmware Upgrade
< SNMP Setup >
The IP dongle can manage the connected W series PDUs in a single daisy-chain up to 16 PDUs via
SNMP v2c ( Simple Network Management Protocol).
Only IP dongle model : IPD-02-S or IPD-H02-S can support SNMP
( I ).
Accessing MIB Files
Use the World Wide Web (WWW) to download the SNMP MIB fi le at this URL:
http://www.austin-hughes.com/support/utilities/infrapower/IPD-MIB.mib
( II ). Enabling SNMP Support
The following procedure summarizes how to enable the IP Dongle for SNMP support.
Step 1. Connect the IP dongle to a computer. ( Please refer to P.12 )
Step 2. Open the Internet Explorer ( I.E. ) version 8.0 or above
Step 3. Enter the confi gured IP dongle address into the I.E. address bar.
Default IP address is “ 192.168.0.1 “
Step 4. Enter “ Login name “ & “ Password “. Default login name & password are “ 00000000 “
