Austin Hughes IPM-03 - Manual (Page 29)

www.austin-hughes.com UM-IPM-03-Q214V3 P.24
After administrator completes < System Setup >, up to 4 additional users can access the
management PC remotely. User can follow the steps below to access management PC &
InfraPower Manager IPM-03
Step 1. Add the port of web server in the fi rewall settings of the management PC.
- Open “ Control Panel ”
- Select “ Windows Firewall “
- Select “ Advanced settings ”
- Right Click “ Inbound Rules ” & select “ New Rule… “
- Select “ Port ” & Click “ Next> ”
- Select ” TCP ” then “ All local ports ” & Click “ Next> ”
- Select “ Allow the connection “ & Click “ Next> “
- Tick all three options & Click “ Next> “
- Input the “ Name “ & “ Description “ of the port & Click “ Finish “
Step 2. Open the web browser of remote client PC
Step 3. Input the URL of InfraPower Manager IPM-03 in the address bar
e.g. http://192.168.0.1/IPM-03/
If the port no. of web server is not 80, please enter the appropriate port no. follow
the IP address e.g. http://192.168.0.1:81/IPM-03/
Step 4. System authentication page pops up automatically.
Input “ User name “, “ Password “ & Click “ Login “
< 3.2 > Remote Access
