9.3.8
Super IO
Feature
Options
Description
Super IO Chip
Info only
W83627DHG Super IO Configuration
Info only
Serial Port 1 Configuration
Serial
Port
Device
Settings
Change
Settings
Enabled
Disabled
IO=3F8h; IRQ=4
Auto
IO=3F8h; IRQ=4
IO=3F8h; IRQ=3,4,5,6,7,10,11,12
IO=2F8h; IRQ=3,4,5,6,7,10,11,12
IO=3E8h; IRQ=3,4,5,6,7,10,11,12
IO=2E8h; IRQ=3,4,5,6,7,10,11,12
Enable/Disable serial port (COM).
Fixed configuration of serial port.
Select an optimal setting for Super IO device.
Serial Port 2 Configuration
Serial
Port
Device
Settings
Change
Settings
Enabled
Disabled
IO=2F8h; IRQ=3
Auto
IO=2F8h; IRQ=3
IO=3F8h; IRQ=3,4,5,6,7,10,11,12
IO=2F8h; IRQ=3,4,5,6,7,10,11,12
IO=3E8h; IRQ=3,4,5,6,7,10,11,12
IO=2E8h; IRQ=3,4,5,6,7,10,11,12
Enable/Disable serial port (COM).
Fixed configuration of serial port.
Select an optimal setting for Super IO device.
Parallel Port Configuration
Parallel
Port
Device
Settings
Chagne
Settings
Enabled
Disabled
IO=378h; IRQ=5;
Auto
IO=378h; IRQ=5;
IO=378h; IRQ=5,6,7,9,10,11,12;
IO=278h; IRQ=5,6,7,9,10,11,12;
IO=3BCh; IRQ=5,6,7,9,10,11,12;
Enable or disable parallel port (LPT/LPTE)
Fixed configuration of parallel port.
Select an optimal settings for Super IO Device.
