5.3 X3: LVDS, Serial, Parallel, KB, MS
Pin Signal Pin Signal Pin Signal Pin Signal
1 GND 2 GND 51 LPT/FLPY# 52 RESERVED
3 R 4 B 53 VCC 54 GND
5 HSY 6 G 55 STB# 56 AFD#
7 VSY 8 DDCK 57 RESERVED 58 PD7
9 DETECT# 10 DDDA 59 IRRX 60 ERR#
11 LCDDO16 12 LCDDO18 61 IRTX 62 PD6
13 LCDDO17 14 LCDDO19 63 RXD2 64 INIT#
15 GND 16 GND 65 GND 66 GND
17 LCDDO13 18 LCDDO15 67 RTS2# 68 PD5
19 LCDDO12 20 LCDDO14 69 DTR2# 70 SLIN#
21 GND 22 GND 71 DCD2# 72 PD4
23 LCDDO8 24 LCDDO11 73 DSR2# 74 PD3
25 LCDDO9 26 LCDDO10 75 CTS2# 76 PD2
27 GND 28 GND 77 TXD2 78 PD1
29 LCDDO4 30 LCDDO7 79 RI2# 80 PD0
31 LCDDO5 32 LCDDO6 81 VCC 82 VCC
33 GND 34 GND 83 RXD1 84 ACK#
35 LCDDO1 36 LCDDO3 85 RTS1# 86 BUSY
37 LCDDO0 38 LCDDO2 87 DTR1# 88 PE
39 VCC 40 VCC 89 DCD1# 90 SLCT#
41 JILI_DAT 42 LTGIO0 91 DSR1# 92 MSCLK
43 JILI_CLK 44 BLON# 93 CTS1# 94 MSDAT
45 BIASON 46 DIGON 95 TXD1 96 KBCLK
47 COMP 48 Y 97 RI1# 98 KBDAT
49 SYNC 50 C 99 GND 100 GND
