9.2.6.6 System Management > Power Up
Feature
Options
Description
Power Up
Info only
Power Up watchdog
Attention: F12 disables the Power Up
Watchdog.
Enabled
Disabled
The Power-Up Watchdog resets the system after a certain
amount of time after power-up.
ECO
Mode
Disabled
Enable
Reduces the power consumption of the system.
Power-up
Mode
Attention: The Power-Up Mode only has
effect, if the module is in ATX-Mode.
Turn on
Remain off
Last State
Turn On: The machine starts automatically when the
power supply is turned on.
Remain Off:To start the machine the power button has to
be pressed.
Last State: When powered on during a power failure the
system will automatically power on when power is restored
9.2.6.7 System Management > Smart Fan
Feature
Options
Description
Smart Fan
Info only
CPU
Smart
FanTemperature
Source
CPU Sensor
System Sensor
Select CPU smart fan source.
CPU Fan Mode
AUTO (Smart Fan)
Fan Off
Fan On
Select CPU Fan Mode.
CPU Trigger Point 1
Read only
Trigger Temperature
15
Specifies the temperature threshold at which the BMC
turns on CPU fan with specific PWM level.
PWM Level
30
Select PWM level.
CPU Trigger Point 2
Read only
Trigger
Temperature
60
Specifies
the
temperature threshold at which the BMC
turns on CPU fan with specific PWM level.
PWM Level
40
Select PWM level.
CPU Trigger Point 3
Read only
Trigger
Temperature
70
Specifies
the
temperature threshold at which the BMC
turns on CPU fan with specific PWM level.
PWM Level
63
Select PWM level.
CPU Trigger Point 4
Read only
Trigger
Temperature
80
Specifies
the
temperature threshold at which the BMC
turns on CPU fan with specific PWM level.
PWM Level
100
Select PWM level.
