6 Module Interfaces
This chapter describes connectors with pin outs, LEDs and switches that are used on the module
but which interfaces are not part of the ETX standard specification
6.1 Connector, Switch and LED Locations
Component Side
GbE
Fan
Reset BIOS
CMOS
SW2
DB40
Debug
DisplayPort
XDP port
System
LEDs
PCI IRQ
Selection
SW4
