2.4 Ethernet
X Type: Intel® i211 (MAC/PHY) Ethernet controller
X Interface: 10/100 Mbps on ETX signal connector
(build option for 1000/100/10 Mbps via FPC connector on module, only one output can be
active at a time)
2.5 Multi I/O and Storage
X USB: 4 ports USB 2.0/1.1
X PATA: two PATA IDE with Master/Slave support
o
Controller supports up to UDMA5
(ETX module maximum sustainable speed mode is UDMA2)
o
PIO storage supported (no booting of PIO)
X
SATA: 2 SATA 3Gb/s ports
X SATA SSD: optional SATA SSD 2-64 GB onboard (occupies second external SATA port)
2.6 Super I/O
X
Chipset: Nuvoton W83627DHG-PT
X Serial: 2 high speed RS-232C ports (COM1/COM2)
X IrDA: supports IrDA 1.0 SIR protocol or Sharp ASK-IR protocol
X Parallel: SPP, and EPP mode support (no DMA support)
X Floppy: not supported (no DMA support on SoC)
X PS/2: Keyboard /Mouse
