Page 12 of 43 ASD8P-MT1 Specification
Manufacturer Platform Chipset Manufacturer Platform Chipset
KILLER
Dell 3010 DT Intel® H61 ASRock Z87 Pro3 Intel® Z87
Dell CM6650 Intel® H67 ASRock Fatal1ty H87
Performance
Intel® H87
Dell 8500 Intel® H77 ASRock B85M Pro4 Intel® B85
Dell 760 DT Intel® Q43 ASRock H81M-DGS Intel® H81
Dell 960 DT Intel® Q45 ASRock 970
Extreme3
AMD 970
Dell 790 DT Intel® Q65 ASRock 990FX
Extreme3
AMD 990
Dell 990 DT Intel® Q67 ECS Z87H3-A2X
Extreme
Intel® Z87
Dell 7010 MT Intel® Q77 ECS H87H3-M3 Intel® H87
Dell 9010 DT Intel® Q77 ECS B85H3-M3 Intel® B85
Dell 745 MT Intel® Q965 ECS H81H3-M4 Intel® H81
Highlighted Platforms / Motherboards with known issue
Manufacturer Chipset Description
ASUS Intel® P67
1: The PCIEx16 slot shares bandwidth with the PCIEx1 slot and USB3_34
connector.
2. The PCIEX16 runs at x1 mode by default for system resource
optimization.
The two feature may set the drive to Gen2 X1 mode then the link speed
will be affected.
ASUS Intel® P55
The second PCIe x 16 slot shares bandwidth with the PCIEx1 slot.
When any of the PCIe x1 slots is occupied, the second PCIe x16 slot will
be limited to x1 mode.
The feature may set the drive to Gen2 X1 mode then the link speed will be
affected.
ASUS Intel®Z68
1: The PCIEX16_1 slot shares bandwidth with the PCIEX16_2 slot
2. The PCIEX16_3 runs at x1 mode by default for system resource
optimization.
3. Depend on bandwidth sharing mode, the SSD might link to Gen2x1
even though you insert graphic card to PCIEX16_1 slot and SSD to
PCIEX16_2 slot.
The feature may set the drive to Gen2 X1 mode then the link speed will be
affected.
