Hardware Information
Pin Definition
Pin
Definition
IDO_n
Isolated digital output channel n
VDD9
common VDD junction for input channel 64-71
VDD10
common VDD junction for input channel 72-79
VDD11
common VDD junction for input channel 80-87
VDD12
common VDD junction for input channel 88-95
VDD13
common VDD junction for input channel 96-103
VDD14
common VDD junction for input channel 104-111
VDD15
common VDD junction for input channel 112-119
VDD16
common VDD junction for input channel 120-127
IGND
Ground return path for isolated output channels
V5V
Onboard un-regulated 5V power supply output
N/C
No Connect
