12 Hardware Information
Bracket Layout
Figure 2-4: PCI-7440 Series Card Bracket
Connector Pin Reference
Figure 2-5: PCI-7440 Series Connector Pin Reference
CN2B
CN1B
CN2A
CN1A
Terminal B68 Terminal B34
Terminal A1 Terminal A35
CN2B CN2A
Terminal A68
Terminal B35 Terminal B1
Terminal A34
Terminal B68 Terminal B34
Terminal B1 Terminal B35
Terminal A68
Terminal A34
Terminal A35 Terminal A1
CN1B CN1A
