C Language Library • 65
For the ACL-8112DG card, the gain values supported are 1, 2, 4, and 8.
The relationship between analog input voltage range, gain and input
type are specified in the table below.
** this table only applies for the ACL-8112DG ( low gain) card.
AD_INPUT GAIN
Input type
(Bipolar or
Unipolar)
Input Range
AD_B_5_V 1 Bipolar ±5V
AD_B_2_5_V 2 Bipolar ±2.5V
AD_B_1_25_V 4 Bipolar ±1.25V
AD_B_0_625_V 8 Bipolar ±0.625V
AD_U_10_V 1 Unipolar 0V to 10V
AD_U_5_V 2 Unipolar 0V to 5V
AD_U_2_5_V 4 Unipolar 0V to 2.5V
AD_U_1_25_V 8 Unipolar 0V to 1.25V
For the ACL-8112PG card, the gain values supported are 1, 2, 4, 8, and
16.
The initial value of the gain is '1'. The relationship between gain and
input voltage ranges is specified by following tables:
When input voltage range is set to
±5 V (JP9),
Gain Code Gain Input Range (V)
AD_GAIN_1 X 1 ±5 V
AD_GAIN_2 X 2 ±2.5 V
AD_GAIN_4 X 4 ±1.25 V
AD_GAIN_8 X 8 ±0.625 V
AD_GAIN_16 X 16 ±0.3125V
When input voltage range is set to ±10 V(JP9),
Gain Code Gain Input Range (V)
AD_GAIN_1 X 1 ±10 V
AD_GAIN_2 X 2 ±5 V
AD_GAIN_4 X 4 ±2.5 V
AD_GAIN_8 X 8 ±1.25 V
AD_GAIN_16 X 16 ±0.625 V
