Introduction • 5
• ACL-8112PG:
Bipolar : ± 10V, ± 5V, ±2.5V, ±1.25V, ±0.625V
Or
Bipolar : ± 5V, ±2.5V, ±1.25V, ±0.625V, ±0.3125V
• Conversion Time: 8µs
• Overvoltage protection: Continuous ± 35V maximum
• Accuracy:
(ACL-8112HG)
GAIN = 0.5, 1 0.01% of FSR ±1 LSB
GAIN = 5, 10 0.02% of FSR ±1 LSB
GAIN = 50, 100 0.04% of FSR ±1 LSB
GAIN = 500, 1000 0.04% of FSR ±1 LSB
(ACL-8112DG)
GAIN = 0.5, 1 0.01% of FSR ±1 LSB
GAIN = 2, 4 0.02% of FSR ±1 LSB
GAIN = 8 0.04% of FSR ±1 LSB
(ACL-8112PG)
GAIN = 0.5, 1, 2, 4 0.015% of FSR ±1 LSB
GAIN = 8, 16 0.02% of FSR ±1 LSB
• Input Impedance: 10MΩ
• AD conversion trigger modes: Software, Pacer, and External trigger
• Data Transfer: Pooling, DMA, Interrupt
• Sampling Rate:
• 100 KHz maximum for single channel
• 100 KHz maximum for multiplexing on ACL-8112PG
• 20 KHz maximum for multiplexing on ACL-8112DG/HG
Analog Output (D/A)
• Converter: DAC7541 or equivalent, monolithic multiplying
• Number of channels: Two double-buffered analog outputs
• Resolution: 12-bit
