Operation Theory • 47
M2, M1 & M0 - Select Operating Mode ( Bit 3, Bit 2, & Bit 1)
M2 M1 M0 MODE
0 0 0 0
0 0 1 1
x 1 0 2
x 1 1 3
1 0 0 4
1 0 1 5
BCD - Select Binary/BCD Counting ( Bit 0)
0 16-BITS BINARY COUNTER
1
BINARY CODED DECIMAL (BCD) COUNTER (4
DIGITAL)
Note: The count of the binary counter is from 0 up to 65,535 and the count
of the BCD counter is from 0 up to 9,999
Mode Definitions
With the 8254, six operating modes can be selected:
• Mode 0: Interrupt on Terminal Count
• Mode 1: Programmable One-Shot.
• Mode 2: Rate Generator
• Mode 3: Square Wave Rate Generator
• Mode 4: Software Triggered Strobe
• Mode 5: Hardware Triggered Strobe
Detail description of these six modes can be found in the Intel Microsystems
Components Handbook Volume II Peripherals.
