7. INDEX
Name Function Page
CN1 64 pin PC/104 connector bus A & B 2-3
CN2 40 pin PC/104 connector bus C & D 2-3
J1 External Battery Header 2-2
SW1 I/O port, memory and SSD select 2-4
JP1-1 & JP1-2 Battery Charge Select 2-2
JP1-3~JP1-5 1Mx8 EPROM select 2-7
M1, M2, & M3 Memory type select 2-7
Note:
If the content in Setting is inconsistent with the CD-ROM, please refer to Setting as the priority.
