MVP MANUAL
(21) Model table reference [TBL command]
Input :
TBLhih
2
Explanation : hh model data No. (Refer to the M command for the model data No.)
• Displays the data table of the model data hih
2
model.
When hih
2
is omitted, displays the data table of the model connected to the VS board currently.
(Example)
: TBL
MODEL NO.=09 AUTO (Indicated autolocked to PC98.)
ADDR
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
C140
09
@
48
30
08
48
01
45
06
40
38
20
FF FF FF FF
C150
FF 05
64
32
04
40
00
30
04
00
11
FF FF FF FF FF
C160
FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF
C170
FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF FF
The address of
©
is:
C140 (Left number) +1 (Top number)=C141 address.
This address is considered as the hexadecimal address conforming to C140.
The relative addresses on the table are as follows. (Not model data.)
ADDR
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
00
01
02
03
04
05
06
07
08
09
0A 0B
0C 0D
0E
0F
10
11
12
13
14
15
16
17
18
19
1A 1B
1C 1D
1E
1F
20
21
22
23
24
25
26
27
28
29
2A 2B
2C 2D
2E
2F
30
31
32
33
34
35
36
37
38
39
3A 3B
3C 3D
3E
3F
170
