MVP MANUAL
Lane exclusively for control boards ■
Lane exclusively for option boards ■
Lane exclusively for input boards ■
Lane exclusively for output boards ■
L1
L2
L3
L4
Insertion
lane
Insertion
lane
Insertion
lane
Insertion lane
Power unit
Only
service
personnel
should
touch
this.
Board insertion lane Rear panel connector (refer to the diagram of the rear panel on page 18)
L2 ^ OPTION
L3 ^ V IN
L4 ^ V OUT
The board insertion lanes and rear panel connectors are paired as shown above.
