MVP MANUAL
5. MVP VIDEO OUTPUT MODES
• The video output formats set by the mode switches are as shown in the following table.
(At shipment, the mode switch value is set to ”8”.)
Mode switch No.
Bus format
Output format
Sync signal frequency
Dropout reduction function
VBS, Y/C
NTSC
Standard speed
RGB
OFF
Double speed
Reserved
8
VBS, Y/C
Standard speed
9
NTSC
RGB
ON
A
Double speed
B
C
D
E
F
Reserved
• Bus format
: NTSC. . . . . . . . . . . . . . . . . . . . . . . . . . NTSC digital signal transmission method.
• Output format
: VBS (VIDEO signal), Can be switched between Y/C and RGB.
However, VBS and Y/C can only be used for the standard speeds.
• Sync signal frequency : Standard speed. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Horizontal 15.734 kHz, vertical 59.94 Hz interlace
: Double speed. . . . . . . . . . . . . . . . . . . . Horizontal speed 31.469 kHz, vertical 59.94 Hz non-inter
lace
• Dropout reduction function: Function for alleviating dropout due to the scanning line structure particular to
multi vision systems
NOTE:
With the RMD-V2550U, only standard speed input is possible. Double speed signals can not be displayed.
