MVP MANUAL
*6 : Display of remote and manual states
REMOTE MODE
MANUAL MODE
*7 : Slot number
*8 : Type of input board
NTSC BOARD
V.SCAN BOARD
NO BOARD
*9 : NTSC input board state
STANDARD MODE
NO STANDARD MODE
Remote state
Manual state
NTSC input board
Variable scan board (option)
No input board is incorporated
: When standard NTSC signal is input
: When non-standard NTSC signal is input
^ 10: Display of VBS/ | Y/C | select switch state
VBS : Composite video signal input (Indicates V FIL.ON for the V.SCAN BOARD)
Y/C : Y/C separation signal input (Indicates V FIL.OFF for the V.SCAN BOARD)
U1: Type of output board
4 OUT BOARD : 4 output board
NO BOARD : No output board is incorporated
5. To perform NTSC input board picture quality adjustment
(1) To set the adjustment mode [AJYC command]
(2) To exit the adjustment mode [AJN command]
Input: AJYC [J|, AJN (3
Explanation: AJYC command : Sets the NTSC input board to the adjustment mode.
AJN command : Exists the adjustment mode. •
• When adjusting the NTSC input board, the adjustment command will be ignored if AJYC is not
executed.
* To set the optional variable scan board to the adjustment mode:
: Use the :A command. (Refer to page 156 and on.)
153
