MVP MANUAL
3. INSTRUCTIONS FOR USING A COMPUTER AS A TERMINAL
• Use commercially available communications software.
• Use PC-DOS internal commands (TYPE, COPY, etc.)
Pay attention to use because only one-way transmission of data is possible in this case.
• Use commercially available communications software (CCT 98, etc.)
• Use the MS-DOS commands (TYPE, COPY, etc.)
Pay attention to use because only one-way transmission of data is possible in this case.
100 OPEN ”COM1:9600, N, 7, 1” AS#1
110 ON COM1 GOSUB * RCV
120 COM1 ON
130 * LOOP
140
A$=INKEY$:IF A$=”” THEN *
LOOP
150
PRINT#1,A$;
160
GOTO * LOOP
170 * RCV
180
IF LOC(1)<>0
then
INPUT$(LOC(1),#1);
190 RETURN
Set the CCT98 communication mode before executing the MVP commands.
After starting up CCT98,
. . . . . . . . . . . . Enter the parameter setting mode.
Set the following items as follows.
F6
Communication speed
2400
4800
Character length
7 bits
8 bits
Stop bit
1 bit
2 bits
Parity bit
None
ODD
9600 19200
Character code
Transmission carriage return code
Reception carriage return code
SI/SO control
X control
EVEN
NEC
CR
CR
None
None
. . . MVP setting at shipment
— Selectable
Fixed
Problems may occur in signal transfer at 2400 bps when adjusting the optional variable scan board.
Refer to the CCT98 manual for how to use the CCT98.
