YAZ SYSTEM SPECIFICATIONS
Power source
Current consumption
(per station)
Communication
Communication channel
Station selection
Wiring
Wiring distance
Permitted line resistance
DC 24V. Use one PS-24N power supply for every 30 stations.
Maximum 150mA.
20mA in standby mode.
Simultaneous by handset.
Maximum 3 channels.
2-digit dial ( [T^ ~ [^ ).
2- twisted pairs in parallel @ >E
l
I 0 ) ^ communication channel.
3- twisted pairs in parallel ([T] [2^,, [+] ) for 2 communication channels.
4- twisted pairs in parallel (|^ [2],[^ [|^ ,[^ [^, [+] [)|] ) for 3 communication
channels.
Total wiring distance should not exceed 2.9 km (1.8 mile) with 0.8 mm dia. (20AWG) cable.
Less than 200 ohm. loop for communication line.
Less than 20 ohm loop for power line.
COMPONENTS AVAILABLE FOR USE WITH YOUR YAZ SYSTEM
Station unit Accessories (for optional functions)
€■
YAZ-90-3: Phone type inter­
com, wall mount (3 commu­
nication channels).
YAW-R: Paging adaptor for
one zone.
u
Power supply
Kg
PS-24N: Power supply
adaptor. OnePS-24Nis
required for every 30 stations.
YAW-RA: Paging adaptor for
up to 8 zones with multiple
selective zones and all page.
PB-YKX: Talkback adaptor.
Required for each talkback
paging zone.
Accessory
YAK-A: Terminal box with
cord and connector for desk-top use. 1?.
YAW-S: Remote control
adaptor for lighting, etc.
PRE-INSTALLATION INSTRUCTIONS
'* For details, please refer to the Instructions packed
with each unit.
1. Use twisted pair cable, not straight conductors.
(1) YAZ-90-3 phone employs such components as CPU (microprocessor) and IC chips. Twisted-pair cable must be used to
prevent the unit from being interfered by line inductive noises generated by the surrounding electrical appliances and
from crosstalk and mulfunction caused by cable conductors themselves.
(2) Keep at least 30 cm (!') away from other cable, like AC power lines or paging speaker lines or telephone lines or provide
metal conduit for running cable.
-
