ТМО-3394704
PARTS LIST FOR
SINGLE SPEED TRANSAXLE LEFT HAND 6^3-0077
REF.
NO.
PART
NO.
DESCRIPTION
REF.
NO.
PART
NO.
DESCRIPTION
1
732-0614
Wire Ring
34
719-0313
Lower Housing
2
716-0171
Retaining—Ring
35
718-0150
Anti-Rotation Brkt.
3
710-0854
Hex Bolt 1/4-2C X 1.75" Lg.*
38
712-0273
Hex Nut 5/16-24 Thd.
4
710-0809
Hex Tap Scr. 1/1-20 x 1.25“ Lg.
39
736-0271
Fl-Wash. .344" I.D. x .875" O.D.
5
717-0764A
Upper Housing
40
717-0772A
Actuating Arm
8
711-0861
Input Shaft
41
761-0198
Brake Yoke
10
736-0335
Thrust Washer 5/8" I.D. x
42
717-0682
Puck Pl.ite
1.25" O.D.
43
717-0578
Brake Puck
11
717-0633
Pinion input 14T
44
717-1022
Axle L.H. Ass y.
12
716-0171
Retaining Ring
45
751-0202
Brake Disc
13
717-0942
Drive Shaft—L.H. Brake
46
741-0337
Flange Bearing 5/8" I.D. x
14
741-0336
Flange Brg. 5/8" I.D. x 3/4" Lg.*
15/16" Lg.
15
717-1362
Bevel Gear 42T Small ,.D.
48
611-0011
Shift Fork Ass'y.
16
717-1363
Bevel Gear 42T Large I.D.
49
741-0862
Ball Detnnt .250" Dia.
17
718-0228
Clutch Collar
50
732-0863
Spring Detent
18
717-1020
Miter Gear 15T (H.D.)
52
741-0335
Needle Brg. 5/8" I.D. x 1/2“
19
716-0184
Retaining Ring
Lg.
20
741-0589
Thrust Bearing
54
736-0319
Fl-Wash. 5/8" I.D.
X
1" O.D.
21
710-0862A
Pan Head Scr. 1/4-20 x .50"
X
.020 Thk.
Lg. w/Patch
55
741-0343
Actuating Pin 5/16" Dia.
22
717-1023
Axle R.H. Ass’y.
56
710-1206
Hex Wash. Hd. Self-Tap Scr.
23
741-0340
Sleeve Bearing 3/4" I.D. x 1.0"
1/4-20 Thd.
Lg-
57
717-1364
Differential Gear 58T
24
721-0179
Oil Seal 3/4" I.D.
58
736-0349
Fl-Wash. 5/8" I.D. x 1" O.D. x
25
750-0767
Axle Spacer
.020 Thk.
26
736-0445
Fl-Wash. .760" I.D. x 1.5" O.D.
736-04&5
Thrust Wash. 5/8" I.D. x 1"
27
711-0918
Cross Shaft
O.D.
X
.025" Thk.
28
717-1252
Differential Can Ass'y.
60
**
Washer (See Below)
29
—
Part of Ref. 28
—
737-0148
Grease—Shell (15 oz.)
32
* *
Washer (See Below)
**Ref. No. 32 736-0495 Thrust Wash. 5/8" I.D.
k
1 “ O.D. x .025 ' Thk.
736-0336 FI-Wash. 5/8" I.D. x 1" O.D. x .030" Thk.
736-0494 Thrust Wash. 5/8" I D. x 1" 0.0. x .035" Thk.
736-0337 FI-Wash. 5/8" I.D. x 1" O.D. x .040" Thk.
**
**Ref. No. 60 736-0492 Fl-Wash. .76“ !.D. x 1.5" O.D. x .010" Thk.
736-0493 Fl-Wash. .76" I.D. x 1.5" O.D. x .020" Thk.
736-0351 Fl-Wash. .76" I.D. x 1.5" O.D. x .030" Thk.
736-0445 Fl-Wash. .76" I.D. x 1.5" O.D. x .060“ Thk.
31
