TMO-3394704
11.5 H.P. 38" LAWN TRACTOR
FARTS LIST FOR MODEL TMO-3394704
REF.
NO.
PART
NO.
DESCRIPTION
REF.
NO.
PART
NO.
DESCRIPTION
1
17932
Gas Tank Support Brkt.
49
736-0217
L-Wash. 3/8“ I.D.—H.D.
2
17933
Pedestal
50
712-0241
Hex L Nut 3/8-24 Thd.
3
710-0118
Hex Bolt 5/15 18x.75"Lg.*
52
710-0473
Truss Mach. Scr. #10-24 x
4
725-0963
Bulb
.5" Lg.
5
710-0258
Hex Bolt 1/4 X .62“ Lg.
53
723-0308B
Foot Pad—R.H.
6
725-1651
Socket
54
723-0309B
Foot Pad—L.H.
7
712-0267
Hex Nut 5/16-18 Thd.*
57
712-0380
Lock Nut 1/4-28 Thd.
8
725-0634
Light Switch
59
723-0302
Hood Stop
9
751-3071
Gas Cap
62
732-0699
Hood Spring
10
726-0205
Hose Clamp
64
712-0272
Hex Sems Nut #10-24 Thd.
11
726-0209
Cable Tie
65
736-0413
Spr. Wash. .39" I.D. x .62" O.D.
12
736-0119
L-Wash. 5/16" I.D.*
66
738-0724
Shid. Bolt
13
725-0267
Ignition Switch
67
749-0722B
Grille Support
14
725-0201
Ignition Key
68
731-0511-81
Trim Strip 81" Lg.
15
751-0553
Fuel Tank
72
746-0616A
Choke Control
16
751-0535-15
Gas Line 15” Long
73
831-C823A
Throttle Control Box
17
761-0194
Blade Brake Ass’y.
74
710-0779A
Truss AB-Tap Scr. #10 x .5"
18
710-0134
Carriage Bolt 1/4-2i) x .62"
75
746-0501
Throttle Wire
19
710-0793
Ribbed Neck Bolt 3/8-24 x .8"
76
757-0345
Seat Assembly
20
15607D
Seat Pivot Brkt.
78
736-0159
FI-Wash. .344" I.D. x .88“ O.D.
21
17590
Rear Fender
79
722-0160
Bushing
22
17704
Seat Hinge Supoort Brkt.—R.H.
83
710-0227
Hex Tap Scr. #8 x .5" Lg.
23
17703
Seat Hinge Support Brkt.—L.H.
84
725-1439
Safety Switch (Seat)
24
17553
Deck Lift Index Brkt.
85
732-0581B
Ext. Spring 5.31" Lg.
25
725-0514A
Battery
86
17239A
Seat Lift Brkt.
26
710-0817
Hex Self-Tap Screw 5/6-18 x
87
726-0278
Insulator Boss Plate
1.25“ Lg.
88
738-0155
ShId. Bolt A37“ Dia. x .162" Lg.
27
710-0255
Truss Mach. Cor. 1/4-20 x .75"
89
738-0296
ShId. Bolt .437" Dia. x .268" Lg.
Lg.
90
736-0141
Spr. Wash. .445" I.D. x .75"
28
710-0726
Hex AB-Tap Scr. 5/16 x .75" Lg.
O.D.
29
710-1017
Torx Mach. AB-Tap Scr. 1/4 x
91
710 0604
Hex Wash. Hd. Scr. 5/16-18 x
.62" Lg.
.62" Lg.
30
710-0623
Hex Self-Tap Scr. 3/8-16 x
92
726-0279
Insulator Plate
.75" Lg.
94
723-0423
Cente' Foot Pad
31
712-0287
Hex Nut 1/4-20 Thd *
95
725-1303
Safety Switch (Seat)
32
736-0607
External L-W;.sh. 5/16" I.D.
96
731-1228
Dash °anel
33
731-0871A
Battery Box w^Cover
97
17782
Retainer Clip
34
732-0588
Compression .Spring
98
710-0351
Truss Mach. B-Tap Scr. #10 x
36
736-0242
Bell-Wash. 5/18" I.D.
.5" Lg.
37
736-0329
L-Wash. 1/4" i.D.*
99
726-0130
Speed Nut
40
736-0270
Bell-Wash. .205" I.D. x .75"
100
714-0104
Internal Cotier Pin 5/16" Dia.
41
710-3009
Pan Hd. Scr. 10-24 X .75" Lg.
101
731-1099A
Lens
42
736-0400
FI-Wash. .218" I.D.
x
.62"
102
725-0925
Ammeter
45
17931A
Grille
103
712-3007
Hex Jam Nut 5/16-18 Thd.
46
17595
Grille Mtg. Brkt.—L H.
104
710-0599
Hex Wash. Hd. Tap Scr.
47
17596
Grills Mtg. Brkt.—R.H.
1/4-20
X
.5“ Lg.
48 17941
Hood
'Common Hardware—May be purchased locally.
IMPORTANT: DO NOT order parts by reference
numbar (Pof. Me
NOTE: Specifications subject to change with out
notice or oblioarion.
