TMO-3394704
11.5 H.P. 38" LAWN TRACTOR
PARTS LIST FOR MODEL TMO-3394704
REF.
NO.
PART
NO.
DESCRIPTION
REF.
NO.
PART
NO.
DESCRIPTION
1
17584
Front Axle Ass'y-—R-H.
29
750-0532
Spacer .985" I.D.
2
17585
Front Axle Ass'y.—L.H.
30
750-0535
Spacer .380" I.D.
3 16481
Steering Arm
31
17548
Front Pivot Bar Support Brkt.
4
710-0152
Hex Bolt 3/8-24
X
1” Lg.*
32
17547
Rear Pivot Bar Support Brkt.
5
710-0538
Hex Bolt 5/16 18x .62"
33
683-0002
Pivot Bar Ass’y.
(Spec.)
35
734-0863
Front Wheel Ass'y. Comp.**
6
710-0772
Hex Bolt 5/16-24x2“ Lg.*
734-0864
Tire Only**
7
723-3018
Ball Joint 3/8-24 Thd.
734-C997A
Rim Only
8
711-0838
Steering Drag Link
737-0280
Grease Fitting
9
712-0237
Hex L-Nut 5/16-24 Thd.
37
734-0255
Air Valve
10
712-0241
Hex Nut 3/8-24 Thd.
38
741-0487A
Bearing
11
712-0267
Hex Nut 5/16-18 Thd.*
42
712-0237
Hex L-Nut 5/16-24 Thd.
12
712-0446
Hex Jam Nut, 3/8-24 Thd.
43
741-0501
Steering Column Brg.
13
714-0470
Cotter Pin 1/8 Dia.
44
710-0837
Cr-Sunk Scr. #10
X
5/8 " Lg.
14
717-0622A
Steering Gear Segment
45
731-0805
Steering Wheel
15
723-3018
Drag Link Bali joint 3/8-24
46
731-0220
Steering Wheel Cap
Thd.
47
731-0484A
Hub Cap
16
726-0214
Push Cap
48
731-0559
Bellov; Steering Column
17
736-0119
L-Wash. 5/16" I.D.*
49
736-0242
Bell-Wash. .345" I.D. x .88"
18
736-0169
L-Wash. 3/8" I.D.*
50
712-0798
Hex Nut 3/8-16 Thd.*
19
736-0187
FI-Wash. .64" I.D.
X
1.24"
51
738-0527
ShId. Bolt 1/2" Dia.
X
2.04“
20
736-0343
FI-Wash. .340" I.D. x 1.125"
52
736-0356
Bell-Wash. .39" x 1.38“ O.D.
22
736-0271
Spr. Wash. .32" I.D. x .62"
54
731-1134
Plastic Tube
23
736-0285
FI-Wash. .635" I D. x 1.585“
55
17545
Pivot Bar Side Plate—L.H.
24
17198
Retainer Plate
56
17546
Pivot Bar Side Plate—R.H.
25
738-0141
Shid. Bolt .437" Dia. x .350"
58
710-0604
Hex Wash. Tap Scr. 5/16-18 x
26
738-0730
Steering Shaft
.62“ Lg.
27
741-0487A
Hex Flange Erg. .632" I.D.
59
736-0217
L-Wash. 3/8" I.D. (H.D.)
28
747-0753
Tie Rod 20" Lg.
61
741-0225
Hex Flange Brg. .634" Dia.
•Common Hardware—May be purchased locally.
IMPORTANT: DO NOT order parts by reference
number (Ref. No.).
••Note: If brand cf tire is in-portant, order by part number and
description (description is printed on the sidewall of tire) [i.e.
Armstrong Super Turf, Goodyear Softrac, Carlisle Turf Saver, etc.].
Part No.
Description
788-0638
Red Spray Paint
777-5268
Steering Cap Label
777-"'190
Labels—Side of Hoed
777-0491
“Montgomery V^/ard’’ Logo—
Rear Fender
770-8085G
Operating Manual
25
