Page 34 of 160 Obey™ 40 User Manual Rev. 7
6. T
ECHNICAL
I
NFORMATION
Maintenance To maintain optimum performance and minimize wear, fixtures should be cleaned
frequently. Usage and environment are contributing factors in determining frequency. As a
general rule, fixtures should be cleaned at least twice a month. Dust build-up reduces light
output performance and can cause overheating. This can lead to reduced lamp life and
increased mechanical wear. Be sure to power off fixture before conducting maintenance.
1. Unplug product from power.
2. Use a vacuum or air compressor and a soft brush to remove dust collected on external
vents.
3. Clean all lenses when the fixture is at room temperature with a mild solution of glass
cleaner or isopropyl alcohol and a soft lint-free cotton cloth or lens tissue.
4. Apply solution to the cloth or tissue and drag dirt and grime to the outside of the lens.
5. Gently polish optical surfaces until they are free of haze and lint.
Always dry the parts carefully after cleaning them.
Technical
Specifications
WEIGHT & DIMENSIONS
Length
19 in (483 mm)
Width 3.5 in (89 mm)
Height 6.7 in (171 mm)
Weight 5.7 lb (2.6 kg)
Power
Auto-ranging external power supply
100–240 VAC, 50/60 Hz
Power consumption @ 120 V <1 W (500 mA) max, 0.2 A inrush
Power consumption @ 230 V <1 W (500 mA) max, 0.2 A inrush
INDOOR/OUTDOOR
Rating
For indoor use only
Thermal
Maximum ambient temperature
104 °F (40 °C)
Control & Programming
Data output
3-pin XLR
Data pin configuration pin 1 ground, pin 2 (-), pin 3 (+)
Total DMX control channels 192
Ordering Information
Obey™ 40
OBEY40
WARRANTY INFORMATION
Warranty
2-year limited warranty
