97
4
i NOTE
•­­If­data­are­not­available­to­display­the­trend­graph,­the­No­Data­Available­screen­is­displayed.
•­Trend­graphs­do­not­include­corrupt­results­or­control­results.
•­­Trend­graph­data­is­cleared­if­bolus­advice­data­is­cleared.
•­­If­ ­(time­change­icon)­is­shown­at­the­bottom­of­the­Trend­Graph­screen,­the­time­and­date­of­one­or­more­
data­points­in­the­trend­graph­may­not­match­the­time­stamp­in­My­Data­because­the­meter­clock­has­been­
changed.­All­times­in­the­trend­graph­show­the­data­relative­to­the­current­meter­time.
For­example:
1.­You­take­a­bG­test­and­the­value­is­stored­in­the­meter­at­9:00.
2.­The­meter­time­is­changed­ahead­1­hour.
3.­The­bG­data­on­the­trend­graph­is­shown­at­10:00.
•­­On­the­right­side­of­the­graph,­the­Maximum­Bolus­Amount­Indicator­is­a­horizontal­line­with­the­corresponding­
value­shown­above­it.­The­purpose­of­this­indicator­is­to­scale­the­top­portion­of­the­graph­for­the­Bolus­Value­
blue­bars.­The­Maximum­Bolus­Amount­Indicator­values­available­on­the­meter­are­1,­5,­15,­30,­and­60­U.­The­
indicator­displayed­is­based­on­the­single­largest­bolus­insulin­amount­delivered­for­the­time­range­chosen.­For­
example,­if­the­largest­bolus­delivered­during­the­chosen­time­range­is­8­U,­then­the­meter­will­scale­the­upper­
graph­to­be­between­0­and­15­U.
•­­On­the­right­side­of­the­graph,­the­Maximum­Carbs­Amount­Indicator­is­a­horizontal­line­with­the­corresponding­
value­shown­below­it.­The­purpose­of­this­indicator­is­to­scale­the­bottom­portion­of­the­graph­for­the­Carb­
Value­dark­orange­bars.­The­Maximum­Carbs­Amount­Indicator­values­available­on­the­meter­are­30,­60,­120,­
180,­and­240­g,­or­the­equivalent­scale­for­BE,­KE,­or­CC.­The­indicator­displayed­is­based­on­the­single­largest­
carbs­amount­for­the­time­range­chosen.­For­example,­if­the­largest­carbs­amount­for­the­chosen­time­range­is­
86­g,­then­the­meter­will­scale­the­lower­graph­to­be­between­0­and­120­g.
•­Select­Table­to­change­the­display­to­the­Table­View.­The­time­range­remains­the­same.
