1.2 The Accu-Chek Aviva Combo Meter at a Glance
Display
Shows­menus,­results,­
messages,­and­data­stored­in­
the­diary
Buttons
Press­to­enter­menus­or­the­
diary,­adjust­settings,­and­
scroll­through­results
Left/Right Soft Keys
Press­to­select­the­menu­or­
option­above­the­key
Power On/Off Button
Press­to­turn­the­meter­on
or­off
Test Strip Slot
Insert­golden­end­of­test­strip­
here
Infrared (IR) Window
Transfers­data­from­the­
meter­to­a­computer
Activation Chip Slot
Activation­chip­is­­
pre-inserted­here
Battery Door
Remove­the­battery­door­
by­pushing­the­tab­and­
pulling­up­the­door
Backlight Button
Press­to­adjust­the­backlight­level
