REPAIR PARTS LIST — GENERATOR
Drawing No. C1273-A
ITEM PART NO. QTY. DESCRIPTION
1 24488 4 TAPTITE #8 X 5/8"
2 24911 4 TAPTITE #8 X 3/8”
3 BN45761 4 STUD-M8-1.25X 160MM
4 81931 1 REAR BEARING CARRIER 15” RV
5 47248 1 BALL BEARING-45 MM
6 81956 1 ASM ROTOR 15” RV 2.5L
7 81955 1 ASM STATOR 15” RV2.5L
8 45770 10 CAPSCREW, HEX HEAD-M5-0.80 X10MM
9 22152 6 LOCK WASHER #10
10 81974 4 HHFC/LW M8-1.25X20 MM
11 74066 4 HHCS,M10-1,25X30 MM
12 22302 4 LOCK WASHER-MI0
13 81952 1 FLEX PLATE-15” RV15M
14 81900 1 RING FAN
15 81192 1 FLYWHEEL MACH.-15” ISM
16 42911 4 CAPSCREW, HEX HEAD-MI0-1.50 X 30 MM
17 81901 1 BAFFLE, AIR RING
18 82737 4 MOUNT, VIBRATION
19 22145 4 FLATWASHER-5/16-M8
20 59450 2 CAPSCREW, SOCKET HEAD-5/16-18 X 1-1/4 LONG
21 75763 1 BOOT, BATTERY CABLE
22 20692 1 MOTOR, STARTER
23 Cl 271 1 ENGINE ADAPTOR-15”, ISM 1L
24 39253 4 CAPSCREW, HEX HEAD-M8-1.25 X 20 MM
25 70936 2 VIBRATION ISOLATOR
26 71956 2 WASHER, VIBRATION ISOLATOR
27 22129 8 LOCKWASHER-5/16-M8
28 72553 2 SCREW, HEX HEAD-M8-1.25 X 60 MM
29 45771 8 HEX NUT, M8-1.25
30 A-24044-A 4 BRUSH ASSEMBLY
31 23877-D 2 HOLDER, BRUSH
32 25105 4 PRHMS 6-32X1/4” SIMS
33 82626 1 COVER, BRUSH
34 BM45761 4 STUD, M8-1.25X30 MM
35 52858 4 NUT FLANGE, HEX-M8-1.25
36 81991 1 WIRE ASSEM.-RED
37 22097 1 LOCK WASHER-1/4-M6
38 22127 1 NUT, HEX-1/4-20
39 22237 4 LOCKWASHER-3/8
40 42909 2 CAPSCR., HEX HD.-M8-1.25 X 30 MM
41 29107 1 GROMMET, RUBBER
42 25155 1 CLAMP
