________REPAIR PARTS LIST — ENGINE COMMON PARTS
Drawing No. 81982-B
ТЕМ PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION
1 81932 1 ENGINE 1L DIESEL 31 69811 1 CAP HEX 1/4" BRASS
2 35586 6 CLAMP, HOSE #20 32 69860-B 1 HOSE-OIL DRAIN
3 81946 1 HOSE-RADIATOR, UPPER 33 74018 4 WASHER, LOCK-MI 2
4 81947 1 HOSE-RADIATOR, LOWER 34 74070 4 M12-1.25 X 40MM HHCS
5 55934 1 HOSE CLAMP 35 70936 2 MOUNT, VIBRATOR
6 22302 4 WASHER, LOCK 36 71956 2 WASHER, VIB. ISOLATION
7 51755 2 M10-1.5X 16MM HHCS 37 22129 12 WASHER, LOCK 5/16"-M8
8 72501 2 SUPPORT, ENGINE 38 51730 2 M8-1.25X 60MM
9 43107 4 M8-1.25X25MM HHCS CAPSCREW
10 81942 1 MANIFOLD, EXHAUST 39 49813 4 NUT, HEX M6-1.0
11 49813 6 NUT, HEX M6-1.0 40 26850 2 SHAKEPROOF EXT 1/4"-M6
12 75674 1 GASKET, EXHAUST 41 22158 4 NUT, HEX #10-32
OUTLET 42 42568 4 M6-1.0X20MM HHCS
13 81975 1 OUTLET, EXHAUST-FLEX 43 22097 6 WASHER, LOCK 1/4"-M6
14 357-70939 1 GASKET, MANIFOLD 44 24114 4 NUT, HEX 5/16"-24
15 42909 1 M8-1.25X30MMHHCS 45 56739 2 SOLENOID, RELAY 12V.
16 81936 1 CHAMBER, AIR INTAKE 46 75763 2 BOOT, RED VINYL
17 70941 1 FILTER, AIR 47 77745 1 CABLE, STARTER
18 42574 1 ADAPTOR, 1/8" NPT-1/8"-28 48 40173 1 CLAMP, HOSE #5.5
19 60108 1 SWITCH, OIL PRESSURE 49 49340 1 BARB, 90 DEG. 3/8" x
20 26204 1 SHAKEPROOF 1/4" NPT
WASHER M6 50 74024 1 PUMP, FUEL ASSEMBLY
21 25507 1 SHAKEPROOF EXT. 7/16" 51 43146 1 M6-1.0X10MMHHCS
22 42568 1 M8-1.25X20MM HHCS 52 45757 1 M10-1.0X25MM HHCS
23 81951 1 HARNESS, ENGINE WIRE 53 57642 2 MlOx 1.5 X40MM HHCS
24 72573 1 BANJO FITTING ASSY. Ml2 54 45772 2 NUT, HEXM10x1.5
25 70928 1 CLAMP, HOSE 55 39253 6 M8x 1.25 x20MM HHCS
26 51716 1 NUT, HEX-M5-0.8 56 72564 1 BRACKET, FUEL FILTER
27 22152 5 WASHER, LOCK #10 57 71910-A 1 LIFTING BRACKET
28 81939 1 BRACKET, OIL DRAIN 58 45771 4 HEX NUT M8-1.25
29 65852 1 CLIP, OIL DRAIN HOSE 59 46233 1 V-BELT, 3/8"-30-1/8" LONG
30 71912 1 M5-0.8
X
8MM PPHMS 60 50190 1 WASHER, FLAT
SPECIAL-M8
17
