EXPLODED VIEW — CYLINDER HEAD
Drawing No. 75678-
11
1
147-70939
1
CYLINDER HEAD ASSEMBLY
2
148-70939
6
EXPANSION PLUG
3
447-70939
3
EXPANSION PLUG
4
149-70939
2
EXPANSION PLUG
5
150-70939
3
INTAKE VALVE
6
151-70939
3
EXHAUST VALVE
7
152-70939
3
VALVE GUIDE SEAL (EXHAUST)
153-70939
3
VALVE GUIDE SEAL (INTAKE)
8
154-70939
6
SPRING
9
155-70939
6
RETAINER
10
156-70939
12
KEY
11
157-70939
6
CAP
12
158-70939
1
CYLINDER HEAD GASKET, 1.2MM THICK
159-70939
1
CYLINDER HEAD GASKET, 1.3MM THICK
13
160-70939
11
BOLT
14
161-70939
3
BOLT
15
162-70939
2
LIFTING EYE
16
163-70939
2
BOLT
17
164-70939
1
TUBING
18
165-70939
2
BOLT
19
60108
1
OIL SWITCH
20
167-70939
1
THERMO-SWITCH
21
168-70939
4
GASKET
22
169-70939
1
WASHER
21
—
