Ariens 935000 - Manual (Page 33)

r
38" MOWER/TONDEUSE 38
935003
NoDE NODE CODE
REF. PIECÉ D'INV
REF. PART STOCK
N0. N0. CODE
DESCRIPTION
QUANTITÉ
NO. REQ'D
N ode
REF.
REF.
NO.
No DE CODE
PIECÉ D'INV.
PART STOCK
NO. CODE
QUANTITÉ
DESCRIPTION
NO. REQ'D
1 072038 F Belt 1 36 062029 M Carriage Bolt, 3/8-16 x 1 PL 1
2 065046 M Locknut, 112-13 2 37 035262 M Tow Pin 1
3 073086 S Idler Pulley 1 38 067029 M Hair Pin, 3/32 X 1-7/8 PL 3
4 055021 M Flange Bushing 1 39 035236 S Mower Strap 1
5 064056 M Washer, .505 ID x .880 00 x .072 4 40 065017 M Jam Nut 6
6 025272
s
Idler Arm 1 4-1 035237 M Tow Hook 1
7 059042 M Cap Screw, 112-13 x 1-114 1 42 025274 S Cover 1
8 003028 M*
Shoulder Bolt 1 43 025398 S Chute Deflector 1
g 083068 F Spring 1 44 025205 S Hinge Pin 1
10 535026 0 Pan (Includes Decals) 45 083145 S Spring, Torsion 1
11 065039 M Locknut, 3/8-16 16 46 022029 S Bushing 1
12 025266
s
Sheave, 4" 1 47 022093 M Zerk Fitting 1
13 064088 M Washer, .750 x .758 x 1)(> x 1.25 1 48 083054 S Spring, Compression 2
14 003419
s Bearing Slinger 4 49 056060 M Seal 2
15 054120 M Radial Bearing 4 51 063008 M Lockwasher, SAE 3/4 2
16 013364
s Spindle Housing 2 52 065025 M Jam Nut 2
17 025264 s Spacer 2 54 067001 F Cotter Pin, 3/32 X 3/4 1
18 066003 s Key, No. 9 Woodruff, 3/16 x 314 2 56 072118 F Mower Belt 1
19 003169
s
Retainer Hub 2 58 035245 0 Brake Band 1
20 003170
s Blade Tray 2 59 064048 M Washer, .750/.760 x 1.375 x .062 PL 2
21 013350 F Mower Blade 2 60 067002 M Cotter Pin, 3/32 X 1 1
22 025265
s Sheave, 1 61 067010 M Hair Pin, Internal, 3/32 x 1-27/64 2
23 059004 M Cap Screw, 3/8-16 x 1 3 62 035248 0 Link 1
24 059023 M Cap Screw, 3/8-16 x 3/4 9 63 067003 M Cotter Pin, 1/16 X 1/2 2
25 013366 M Cap 2 64 064057 M Washer, .312/.343 x .625 x .062 PL 4
26 065058
s Slotted Jam Nut 2 65 035246 0 Brake Rod 1
27 067014 M Cotter Pin, 1/8 X iy< 2 66 058034 M Roll Pin, 1/8 X 3/4 1
28 054045 M Bearing Cone 4 67 065015 M Nut 1
29 054044 M Bearing Cup 4 68 083009 M Spring 2
30 035102 0 Sheave, (Includes Zerk) 1 69 035247 0 Brake Lever 1
31 025281
s
Spacer 1 70 035100 M Hanger Hook 2
32 025267
s
Drive Plate 1 71 063003 M Lockwasher 1
33 062010 M Carriage Bolt, 3/8-16 x 3/4 4 72 035027 M Spacer 1
34 064093 M Washer, .380/.385 X 13/16 X .062 PL 1 73 065061 M Jam Nut 2
35 025271 s
Engagement Bracket 1 74 002813 M Pin 1
75 067033 M Hair Pin 2
. SUGGESTED PARTS STOCKING CODE
F - FAST S -SLOW
M - MEDIUM 0 - CUSTOMER ORDER ONLY
CODE suggéré D'INVENTAIRE DES PIÈCES
F - FAST (rapide) S - SLOW (lent)
M - MEDIUM (moyen) 0 — Commande du client seulement
- 33 -
