FUEL LINES/TUYAUTERIE DE CARBURANT
935003, 935004 & 935005
NoDE N0 DE CODE
REF. PIECÉ D'INV
REF. PART STOCK
N0. N0. CODE
DESCRIPTION
QUANTITÉ
NO. REQ'D
N ode N o DE
REF. PIECE
REF. PART
NO. NO.
CODE
D'INV.
STOCK
CODE
QUANTITÉ
DESCRIPTION
NO. REQ'D
1 069126 F Throttle Control 1 40 059028 M Cap Screw, )i-20 x )i, GR 2 HHPL 2
2 063011 M Lockwasher 2 41 063002 M Lockwasher, SAE STD % 6
3 065055 M Nut, 10-24 UNC. 2 42 065032 M Nut, )k-20 6
4 064001 M Washer, STD. 3/16 X 9/16 X .049 PL 2 43 • 082133 0 11 HP Briggs 1
5 029149 F Ignition Switch 1 Model 252707 - 0186-01, YT11
6 063029 M Lockwasher 1 43 082153 0 6 HP VM60-150 137G Tecumseh YT6 1
7 065106 M Nut, 9/16-24 UNEF 1 44 035310 s Isolation Mount, YT8 2
8 031151 F Light Switch 1 45- 035077 M Bushing, YT11 1
g 065104 M Nut, )i-20 UNF 1 46 035105 F Drain Lock, YT11 1
10 075068 M Knob 1 46 035242 M Drain Elbow, YT6 1
11 029175 M Battery 1 47 030020 F Hose, YT11 1
12 035070
s Hook Bolt 2 46 059170 M Cap Screw, */ie-l8 x 2 Gr 5, YT11 4
13 013044 0 Battery Hold Down 1 48 059131 M Cap Screw, >/„-18 x 2K Gr 2 HHPL, YT8 4
14 064007 M Washer, STD. - % 2
49 064099 M Washer, 5/16 ID x 1-5/8 OD x .135 4
15 065012 M Wing Nut, %-20 UNC. 2
59 063003 M Lockwasher, SAE STD 5/16 4
16 035071
s
Fuel Tank 1
60 065015 M Nut, 5/16-18 GR C 4
17 035072 M Lower Tank Support 1
61 035063 F Gasket YT11 4
18 075093 M Fuel Tank Grommet 1
62 059090 M Cap Screw, 5/16-18 x % Oil Hardened YT11 2
19 035073 M Gas Line Fitting 1
63 069094 M Clamp 1
20 030020 M Hose 1 64 074043 M Tapping Screw, 10-16 x )i 5
21 029106 F Fuel Filter 1
65 059001 M Cap Screw,' )i-20 x % 2
22 030020 M Hose 1
66 065070 M Locknut, 1L-20 2
23 029172 M Hose Clamp 4 67 059028 M Cap Screw, %-20 x IKt GR 2 HHPL 4
24 069053 M Tie Down 1 68 073112 M Sheave, Engine 1
25 031111 M Cable, YT11 1 69 066022 M Key, Straight % x % x 1 1
26 035076 M Fuel Gauge 1 70 031861
s
Bearing Spacer' 1
27 035112 M Exhaust Muffler, YT11 1 71 064157 M Washer, .469 iD x 1.36 OD x .125 1
27
• «
M Exhaust Muffler, YT8 1 72 063005 M Lockwasher, SAE STD 7/16 1
29 535016 0 Dash Base W/Decals 1 73 059153 M Cap Screw, 7/16 - 20 x 1 1
30 029117 0 Dash (use w/Dash Decal 078547) 1 74 035069
s
Spacer 1
31 035004 0 Battery Stand 1 75 060006 M Setscrew, 5/16-18 UNC - 3A x % 2
32 535028 0 Frame W/Decals 1 76 030199 M Hose Clamp, YT11 1
33 059039 M Cap Screw, 5/16-18 x 3/4 GR 5 4 77 035216 s
Bushing, YT8 2
34 0630Q3 M Lockwasher 4 78 059137 M Capscrew 2
35 065015 M Nut, 5/16-18 4 79 069110 M Clip 1
36 075019 M Knob 1 80 035309 s Spacer Tube, YT 8 4
37 013157 F Keys 1 81 035311 s Isolation Mount, YT 8 4
38 035074 M Clamp Strap 1 82 035062
s Engine Spacer, YT 11 4
39 031720 M Solenoid 1
‘"Tecumseh No. 1A120-165 available from Tecumseh Dealers only. "Engines Are Available From Engine Manufacturers Dealers Only.
SUGGESTED PARTS STOCKING CODE
F -FAST S -SLOW
M - MEDIUM 0 - CUSTOMER ORDER ONLY
CODE SUGGÉRÉ D'INVENTAIRE DES PIÈCES
F - FAST (rapide) S -SLOW (lent)
M - MEDIUM (moyen) 0 - Commande du client seulement
- 2 9 -
