Ariens 935000 - Manual (Page 21)

LIFT LEVER/RELEUAGE MANUEL
935003, 935004 & 935005
N ode
REF.
REF.
NO
NoOE
PIECE
PART
NO
CODE
D'INV
STOCK
CODE
QUANTITE
NO. REQ'D
DESCRIPTION
N ode
REF.
REF.
NO.
N ode
PIECE
PART
NO.
CODE
D'INV
STOCK
CODE
QUANTITE
NO. REQ'D
DESCRIPTON
1 035033 S Clutch Pedal 1 43 065051 M Keps Nut, 10-24 1
2 065034 M Locknut, 5/8-18 Centerlock 1 44 035061 S Rod 1
3 064043 M Washer, SAE 3/8 4 45 035005 S Pedal Pivot 2
4 067004 M Cotter Fin, 1/8 X 1, PL 5 46 035241 S Rear Hanger, YT11 1
5 003016 M Shoulder Bolt 2 46 035223 S Rear Hanger, YT8 1
6 065060 M Locknut, 3/8-16 Centerlock 2 47 035225 S Front Hanger Arm - Right 1
7 035035 s Brake Pedal 1 48 035224 S Front Hanger Arm - Left 1
8 035036 M Parking Brake Rod 1 49 031381 M Clevis Pin 2
9 035037 M Brake Rod 1 50 067029 M Hair Pin, Internal .094 6
10 064002 M Washer, STD 5/16 4 -51 035321
s Rod End 1
11 065042 M Locknut, 5/16-18 2 way 3 52 067010 M Hair Pin, Internal 4
12 083091 M Brake Spring 1 53 064003 M Washer, .505 ID x .680 00 x .072 4
13 083178 M Extension Spring 1 54 035023 0 Draw Bar 1
14 075029 M Pedal Cover 2 55 035024 0 Hanger Bracket 2
15 058040 M Pin, Groove, % X 1 • 1 % E 1 57 063004 M Lockwasher, 3/8 SAE STD. 2
16 035045 0 Lift Handle 1 58 065018 M Nut, 3/8-16 2
17 035046 0 Lift Quadrant 1 59 535028 0 Frame, w/Decals 1
18 083104 M Spring 1 60 059154 M Cap Screw, 3/8-16 x 3/16 GR 5, HHPL 6
19 064096 M Washer, 29/64 ID x % x 16 GA 1 61 035034 s Clutch Rod 1
20 035047 0 Plunger Rod 1 63 064008 M Washer, STD. 3/8 1
21 058040 M Roll Pin, % X 1% 2 64 031755 F Belt Finger 2
22 075053
s Grip 1 65 035026 M Cam Actuator 1
23 012128 M Flange Bushing 2 66 059034 M Cap Screw, 5/16-18 x 7/8 GR 2 HHPL 2
24 035048
s
Lift Arm 1 67 035027 M Spacer 2
25 035322
s
Adjustable Link 1 68 064007 M Washer, STD. 1/4 2
26 067021 M Cotter Pin, 1/8 X I'/i, PL 2 71 035167 M Link 1
27 035049
s
Lift Link 1 72 035166 M Cam 1
28 035057
s PTO Lever 1 73 059128 M Cap Screw, 5/16-18 x 1% GR 5 2
29 035058
s
PTO Handle 1 74 035008 0 Center Lift Bracket 1
30 035059 0 Bracket 1 75 035009 0 Center Lift Lever 1
31 059135 M Cap Screw, 5/16-18 x % GR 5 5 76 064062 M Washer, 49/64 ID x 1-1/8 x .062 1
32 063003 M Lockwasher, 5/16 SAE STD. 7 77 067021 M Cotter Pin, 1/8x1 'h 2
33 065015 M Nut, 5/16-18 9 78 062010 M Carriage Bolt, 3/8-16 x 3/4 2
34 055037 F Flange Bushing 1 79 064008 M Washer, 3/8 STD x 1 x .083 PL 1
35 083132 M Compression Spring 1 80 065124 M Locknut, 5/16-18 GR C 5
36 064003 M Washer, SAE 'll STD. x 1/16 x .096 PL 1 81 065017 M Jam Nut, 1/2-13 4
37 058003 M Roll Pin, 3/16x1% 1 82 035206 M Rod 2
38 075001 M Shift Ball 1 83 064007 M Washer, 1/4 Std. 3
39 035060
s Switch Bracket 1 84 065122 M Locknut, 3/8-16 4
40 062011 M Carriage Bolt, 5/16-18 x 3/4, PL 5 85 065046 M Locknut, %-13 1
41 027078 F Switch Interlock 1
42 061050 M Machine Screvk, 10-24 x 1" PL 1
SUGGESTED PARTS STOCKING CODE
F - F A S T S - S L O W
M - MEDIUM 0 - CUSTOMER ORDER ONLY
CODE SUGGERE D'INVENTAIRE DES PIECES
F - FAST Irapide) S - SLOW (lent)
M - MEDIUM (moyen) 0 - Commande du client seulement
21 -
