NOTE;
CAPSCREWS
MUST
BE
LOCATED ON TOP OF VANES
AS SHOWN.
NOTE:
MOUNT
VANt
TO BLADE As
SHOWN
ONLY
WITH
WORD
"FRONT"
EXPOSED
GRADE 8
CAPSCREWS
VANE
LOCKNUTS
FIGURE 22
IMPORTANT:
THE
VANES
(SERVICE
PART
NO.
527011)
MUST
BE
USED
IN
PAIRS.
THEY
CANNOT
BE
INTERCHANGED
WITH
Dlf^FERENT
OR
WORN
VANES ON THÉ SAME BUDE. USING ON| OF EACH
OF A DIFFERENT TYPE OR WORN VANE WILL CAUSE
THE BLADE TO BE OUT OF BALANCE AND SEVERE
VIBRATION
WILL
OCCUR.
EVEN
WEAR
ON
THE
PARTS
AND
PROPER
BALANCE
IS
ENSURED
BY
REPLACING V A N E S P A I R S .
protection while removing mower blade. Remove the
nyt and lockwasher- securing the blade and remove *
blade. See Figure 23.
Sharpen, blade by following the same contour of the’
cutting edge; be careful not to rourvd off the outer cor
ners of cutting edge.
Sharpen both cutting edges fqpally to,
balanced.
The mower blade should always be kept sharp and pro
perly
balanced.
Disconnect
spark
plyg
wire.
Remove
Mower Pan, clear dirt and grass from underside, and
check blade. Use a heavy glove or padding for hand
Replace mower blade In position oh mower and secure
with lockwasher and nut. Torque to 50-55 lbs. Be sur^-.^
to use a heavy gloye or padding for hand protectio 1
while fastening blade.
-14 -
