Engage Bobbin Winder Latch
Hold Thread End to Start Winding
Winding Steps
1. Place thread spool on spool pin over the
spool pin felt Lead thread between tension
discs (as shown}, around thread post and
through small hole in bobbin (from the in
side out).
2. Place bobbin on spindle and engage latch
by pressing it toward the bobbin.
3. Hold thread end as shown and start the ma
chine. Thread end will snap off after a few
coils have been wound on the bobbin.
4. When required amount of thread has been
wound (full bobbin will automatically re
lease), cut thread and remove bobbin from
spindle,
5. Tighten hand wheel knob by turning it away
from you with your right hand while holding
the hand wheel with your left hand.
10
