Sears 536.25587 - Manual (Page 73)

PEERLESS TRANSAXLE MODEL 930-045 FOR 43” TRACTOR MODEL 536.255870
Key
No,
Par! No, Description
1 772108A Cover, Transaxle
2 780086 Bearing, Needle
3 770102A Case, Transaxfe
4 776260 Shaft. Counter
5 776219A Shaft & Pinion Assembly, Output
6 778139 Gear, Output
7 77B136 Gear. Spur {15 teeth)
8 792136 Key
9 784352 Collar, Shifter
10 784355 Rod & Fork Assembly, Shift
11 77B229 Gear. Bevel {42 teeth)
12 778113A Bevel Pinion, Input
13 778221 Gear, Bevel (16 Teeth)
14 778058 Gear, Bevel Nnion
15 778260 Gear, Ring
17 786139 Pin. Drive
18 786102 Spacer
20 792077 Ball, Steel (5/16- Dia.)
21 792078 Set Screw, 3/8-16 x 3/B
22 792079 Spring
23 788061 Ring, Seal
25 792073 Screw, Flanged Hex Hd,
Thread forming, 1/4-20 x 1-1/4
26 792125 Ring, Retainer (Pkg. of 2)
27 792035 Ring. Retainer
28 788040 Ring, Retainer
29 780072 Washer, Thrust
30 780108 Washer, Thrust
31 780001 Washer
32 792001 "0” Ring
33 788051 Seal, Square cut
34 7801OSA Bushing, Flanged
35 780118A Bushing, Flanged
36 790003 Disk, Brake
37 790007 Plate, Brake pad
38 79021 Pad, Brake (Pkg, of 2)
39 786026 Pin, Dowel
40 792076A Washer, Flat
41 790023A Lever, Brake
42 792085 Screw, Flanged Hex Hd,
Thread forming, 1/4-20 x 2-1/4
THIS TRANSAXLE’S CAPACITY IS 24 OZ-
Key
No,
Part No. Description
43 792075 Nut. Lock. 5/16-24
44 790025 Holder, Brake pad
45 786066 Spacer
46 786086 Brake Lever Bracket
47 774951 Axle {8-15/16" long)
48 774952 Axle {13-17/32" long)
49 778183 Gear, Spur (35 teeth)
50 778124A Gear, Spur (30 teeth)
51 778250 Gear, Spur (27 teeth)
52 778123A Gear, Spur (25 teeth)
53 778121A Gear. Spur (20 teeth)
56 778193 Gear, Spur (15 teeth steel)
57 778126A Gear, Spur (20 teeth)
58 778249 Gear, Spur (23 teeth)
59 778127A Gear, Spur (25 teeth)
60 778129A Gear, Spur ( 30 teeth)
63 786071 Countershaft Spacer
64 786072 Output Shaft Spacer
65 780109 Washer
66 776135 Input Shaft
67 776315A Shifter & Brake Shaft
68 786116 Disk
69 780051 Washer
70 786118 Spacer
71 788069 Square Cut Ring
72 792074 Threaded Plug
76 780090 Washer
77 788078A Inverted Retaining Ring (pkg. of 2)
81 786062A Roller Chain (No. 41 chain, 22 links)
82 786061 Sprocket (10 teeth)
83 786124 Reverse Sprocket (14 teeth)
90 788067B Grease (32 oz. btl. Bentonite grease)
150 510334 Gasket Eliminator (Loctite #515)
73
