OPERATION
The operation of any tractor can result in foreign objects being thrown into the eyes, which can result in
severe eye damage. Always wear safety glasses or eye shields while operating your tractor or performing
any adjustments or repairs,,
We recommend standard safety glasses, available at SEARS Retail or Catalog Stores, or a wide vision
safety mask for over your glasses.
CUT
gfiSfr
lO OIAMCE OIT HEICHT
1,, FUU.Y DEPRESS CUT HBSHT
PEDAL
2, POSmON MEMORY ROD TO
DESIRED HEIGHT
3, RB-EASECUTHEiCKT
PEDAL
to yRANSPOR?
1„ FULLY DEPRESS CUT HSGKT
PEDAL
• READ OPERATORS MANUAUS)
- KNOWLOCATIQNSFUHCnoNOF ALL CONTROLS |
■ KEEP GUARDS, SAFETY SHIELDS AND SWfrCHES
INPLACE AND WORKING PROPERLY
. REMOVEOaJECTSTHATCANBETOROWKBY
BU0E(S}
. DOK0TÍÍOWWHENCH1LDREN OR OTHERS ARE
AlfflUND
• NEVER CARRY CHILDREN OH PASSENGERS
■ LOOK DOWN AMD BEHIND BEFORE AND
WHILE BACKING
• DOHOTMOWWHEHEMOWERCANTIPORSUP
• IF MACHINE STOPS GOING ÜP KILL, DISENGAGE
BIADE(S! AND BACK DOWN SLOWLY
• REMOVE ffiY WHEN LEAVING MACHINE
• AVOID SUDDEN TURNS
■ GO UP AND DOWNSLOPES,NOT ACROSS
5>ARKI№S
ВЕШКЕ
LEVES
ALWAYS SET PARKING BRAKE
BEFORE LEAVING OH ENGINE WtL
STOP
ГОЕВПРДЙШМФ ВИДКЕ
1. FULLY DEPRESS BRAKBCLUTCH
PEDAL
2 PUSH LEVER FOWARD AND НОШ
3,, RELEASE BRAKBCLUTCH PEDAL
TO RELEASE РДШСНС BRAKE
1, FULLY DEPRESS BRAKEATLUTCH
PEDAL LEVER WILL RELEASE
OS»ERAtlMG INSTRUCTiOHS...
(READ OWNERS MANUAL)
TO START TO STOP
1 DISENGAGE ATTACHMENT CLUTCH 1, FULLY DEPRESS 8HAKE/CLUTCH PEDAL
2 FULLY DEPRESS BRAKECLUTCH PEDAL 2 DISENGAGE ATTACHMENT CLUTCH
3. SHIFTTONEUTRAL 3 . SHIFITONEUTRAL
4. SETTHROTTLETOFUIL(CHOKE IF NEEDED) 4. ENGAGE PARKING BRAKE
5. TURN IGNITION TO START S TURN IGNITION TO OFF
TO SHIFT CEARS
1 fully DEPRESS BRAKECLUTCH PEDAL
3 SHIFT TO DESIRED GEAR
3 RELEASE HRAKE/CLUICH PEDAL SLOWLY
HOW TO USE YOUR TRACTOR
TO SET PARKING BRAKE
0 Depress brake-clutch pedal fully (all the way down) and
hold.
© Push parking brake lever forward and engage notch in
parking brake lever against main frame.
® To release parking brake, apply pressure to brake-clutch
pedal and spring will automatically release parking brake
lever.
STOPPING
MOWER BLADES -
e Pull the clutch lever rearward to the DISENGAGED
position,
A CAUTION: Blades will not stop Imme­
diately. Keep hands and feet from under
mower deck and away from discharge
chute.
TRACTOR -
• Depress br^e-clutch pedal fully (all the way down),
o Place shift control lever in NEUTRAL position,
8 Set parking brake before leaving tractor,
ENGINE -
e Move throttle control to SLOW position.
• Turn Ignition key to OFF position and remove key, Always
remove key when leaving vehicle to prevent unauthorized
use.
© Never use choke to stop engine,,
NOTE: Under certain conditions when unit is standing
idle with engine running, hot engine gases may cause "brown­
ing" of grass. To eliminate this possibility, always stop engine
when stopping tractor on grass areas.
TO USE CHOKE CONTROL
Use choke control whenever you are starting a cold engine.
Do not use to start a warm engine.
e To engage choke control, pull knob out. Slowly push knob
in as engine warms up to disengage,,
TO USE THROTTLE CONTROL
© FAST throttle position is necessary for best bagging and
mowing performance.
© Operating engine at other than FAST position reduces
battery charging rate and the engine cooling air flow.
TO MOVE BACKWARD AND FORWARD
The direction of motion {fonvard - reverse) and ground
speed ranges (1-2-3-4-5-6) are controlled by shift control
lever.
© Start tractor with brake-clutch pedal depressed and shift
control lever in NEUTRAL position,
© Move shift control lever to reverse or forward speed range.
NOTE: Always come to a full stop before changing direction
of motion.
© Slowly release brake-clutch pedal to start movement.
