CRAFTSMAN 43" LAWN TRACTOR MODEL 536.255870
KEY# PART# DESCRIPTION QTY.
1 327452 MOWER DECKS. RIDER 43' MULCHING 1
2 326480-853 TOE GUARD 1
3 180075 SCREW. S/16-18X ,63 HHC 1
4 1498 NUT, 5« 6-18 REGHEXCTRLK 1
5 122007 SCREW. S/16-18X ,75 HHC 1
e 1498 NUT. 5/16-18 REGHEXCTRLK 1
6A 327280-853 BRACKET, REFLECTOR STOP 1
6B 122027 SCREW. 5/16-18X1.25 1
6C 1498 NUT, 5/16-18 REGHEXCTRLK 1
7 317017 BRACKET CHUTE MOUNT 1
8 180075 SCREW. 5/16-1BX ,63 НИС 2
9 120393 WASHER.FLAT .344X.69X.06S 2
10 1498 NUT. 5/16-18 REGHEXCTRLK 2
11 313929 LIFT BRACKET, REAR.RH 1
12 180077 SCREW, 5/16-18X .75 HHC 2
13 120393 WASHER. FLAT .344X ,69X 065 2
14 1498 NUT. 5/16-18 REGHEXCTRLK 2
IS 310667 BRACKET,DECK LIFTREAH LH 1
16 180077 SCREW. S/16-18X .75 HHC GHS 2
17 120393 WASHER, FUT -344X .69X,D65 2
IB 1498 NUT. 5/16-18 REGHEXCTRLK 2
Ш 326803-853 BRACE IDLER
1ЭА 308231 SCREW. 1/4-20X1,25 HHWATAP t
20 180077 SCREW, 5/16-18X .75 HHC 2
22 4410S NUT, 5/16-18 HWDFLCTRLK
2
23 S6424-853 QUILL ASSY, 36/39/40/43 2
24 56425 SHAFT/SADDLE 36"
1
25 49562 BRN6, BALL
1
26 5061В DUST SHIELD
1
27 55547 QUILL CASTING (1046) 1
28 495Б2 BRNG. BALL 1
29 50818 SPACER,3.797LGX.669iDX,8BOD
1
30 51449 SPACER,-438LGX 9320DX 672ID 1
31 56390 PULLEY .26/36* QUILL V5L 1
32 313898 SPECIAL WASHER 1
33 1282 NUT. 7/16-20 WDFLLK 1
34 50534 SCREW. S/16-1BX ,88 WAHHTAP 7
35 300345 SCREW. 5/16-18X1.38 WATAP 1
36 1498 NUT, S/16-16 REGHEXCTRLK 1
37 313778 BRACKET FHT. 1
38 180075 SCREW, 5/1Б-1ВХ .63 HHC 4
3S 1498 NUT, 5/16-18 REGHEXCTRLK 4
40 58305 LINK BRACKET.DECK FR 1
41 S8247 ADJUSTING NUT 2
42 122017 SCREW. 5/16-18X1.00 HHC 2
43 1498 NUT,S/16-18 REGHEXCTRLK 2
44 304426 BRACKET,GAGE WHEEL L H. 1
45 18007S SCREW, 5/16-18X .63 HHC 3
46 1498 NUT, 5/16-18 REGHEXCTRLK 3
47 322464 BRACKET.GAGE WHEEL H H. FRNT 1
48 314282 BRACKET.STABIUZER 1
4Э 180075 SCREW. S/16-tBX .63 HHC 3
50 1498 NUT. S/1B-18 REGHEXCTRLK 3
51 325762 BLADE, MULCHING 21.70 2
52 2483 WASHER,.39IDX1 2SDX.07 BELLVIL В
53 47665 SCREW. 3/8-24X1 25 NYLHHC GRS 2
54 320576 IDLER ARM ASSY 1
55 322116 IDLER ARM
1
56 41601 RIVET 2
57 306973 BRAKE PAD
1
56 304420 SHOULDER BOLT
59 996416 WASHER,FUT 391X1 00X.125 t
60 996307 WASHER,FUT .391X1.00X 209 1
61 45171 NUT, 3/8-16 HWDFL WHIZ-LOCK 1
62 326249 BRACKET. EXTENSION IDLER 1
63 1B0075 SCREW 5Л6-1ВХ.63 HHC GR.S 1
64 180083 SCREW, S/16-18X1 50HHC GHS 1
65 446363 WASHER,FUT t
66 271184 NUTS/16-1BHEX KEPS 1
67 1498 NUT 2
66 321828 BLADE BRAKE ASSY 1
69 304119-853 BRAKE ARM
1
70 306973 BRAKE PAD 1
71 135624 RIVET 2
72 180075 SCREW, 5/16-ШХ.63 t
73 120333 WASHER.FUT .344Х.6ЭХ.065 t
74 1498 NUT, 5/16-18 REGEHEXCTRLK 1
75 314073 ROD.BRAKE 1
76 1502 NUT,1/4-20 REGHEXCTRLK t
77 35410 SPRING 1
78 327570 KICKER. MULCHER t
79 126216 80LT5/16-18X .75 1
80 1498 NUT. 5/15-18 REGHEXCTRLK 1
55
