ENGINE MODEL 402707-1235^01 FOR 43” TRACTOR MODEL 536.255870
©
21
o 524A
* REQUIRES SPECIAL TOOLS
TO INSTALL SEE REPAIR
INSTRUCTION MANUAL.
REF,
NO
PART
NO. DESCRIPTION
REF.
NO.
PART
NO. DESCRIPTION
REF
NO.
PART
NO. DESCRIPTION
506 231174 Terminal
507 280180 Grammet-lnsulator
S24A *271485 Seal-Plug
S56 93585 Screw-Hex. Hd
569 *270931 Gasket-Crankcase
572 224580 Baffle-Air (Cyl. #2)
869 261463 Seat-Intake Valve
(Standard)
B70 213316 Seat-Exhaust Valve
(Standard)
871 261961 Guide-Exhaust Valve
(Only)
Note: 231218 Guide-Inlake
(Brass)
See Repair Manual
881 222860 Cover Plate-
Crankcase
1019 491261 Label Kit
1 494533
2 491756
3 *391086
5.1 493457
5.2 4934S8
7.1 *271867
7.2 *271868
8.1
8.2
9
10
11
398065
222892
*27803
94382
280225
Cylinder Assembly
Bearing-Cylinder
Seal-Oil
Head-Cylinder #1
Head-Cylinder #2
Gasket-Cylinder
Head #1
Gasket-Cylinder
Head #2
Breather Assembly #1
Cover-Breather
Cylindar #2
(Used Only on Ref.
572 Air Baffle with
Holes for Mounting)
Gasket-Valve Cover
Screw-Sem
Tuba-Breather
12 *271703
*271188
*271189
13
15
ISA
18
945B5
94239
94497
493304
20 *291675
21
399195
22 93882
244 230318
354 90576
Gasket-Crankcase
Cover ¡1/64" Thick)
Gasket-Crankcase
Cover (.005' Thick)
Gasket-Crankcase
Cover (.OOS- Thick)
Screw-Cylinder Head
Plug-Oil Drain
Plug-Pipe (1/8-27)
Base Assy,-
Crankcase
Seal-Oil
Plug Assy-Oil Fill
Screw-Crankcase
Cover Mtg,
Connector-Impulse
Pump
Nut-Hex.
* Included in Gasket Set-Par! No, 491856.
Assemblies Include all parts shown In frames.
