CRAFTSMAN 43" LAWN TRACTOR MODEL 536.255870
KEY# PART# DESCRIPTION QTY, '
1 • ENGiNE.B&S 15HP TWIN OPPI/C 1
2 50947 SCREW. 3/8-16X1.25 WAHHTAPBLKP 4
3 138489 WASHER, EXLK ,384X.69X 04 1
4 305550 MUFFLER, 16Л8НР LARGE LaTONE 1
5 305552 EXHAUST TUBE RH 1
6 305551 EXHAUST TUBE LH 1
7 56640 GASKET, MUFFLER 2
8 180020 SCREW, 1/4-20X .75 HHC 4
9 120380 WASHER, REGSPTLK.263X 49X.07 4
10 56472 DEFLECTOR SIDE OUT (BS222573) 1
11 35287 SCREW, #8-32X .38 HHWATAP 3
12 304709-853 BRACKET,MUFFLER 1
13, 56030 SCREW, 5/16-1BX.75WDFLLK 2
14 55273 NUT, 5/16-18 HXWDFLLK 2
15 995346 SCREW. 1/4-20X .50 WAHHTAP 2
16 9796 BRACKET, TRANSAXLE MOUNTING 1
17 995338 SCREW, 1/4-20X .63 HHWATAP 2
IB 327938-853 SHIELD.MUFFLER HEAT 1
19 180077 SCREW, 5/16-18X .75 HHC 2
20 55273 NUT. 5/16-18 HXWDFLLK 2
21 56470-853 DEFLECTOR, COOL AIR 1
22 328034 PULLEY. ENG V3L 4 00 OFFSET 1
23 303151 KEY, SQUARE .249SQX4 50LG 1
24 304246 SPACER, SLEV1„01X1.4B4X. 1
25 56431 WASHER, 980iDX1.38ODX,437PILOT 1
26 120383 WASHER. REGSPTLK 459X,78X,12 1
27 433146 SCREW, 7/16-20X4 25 HHC BLK PH 1
28, 314992 TANK. FUEL 2 GAL CLEAR 1
2BA 301087-853 SHIELD, HEAT FUEL TANK 1
29 49050 SCREW, 1/4-10X .75PHPNTAP 6
30 41007 TUBING, ,25X,50X BULK GAS LINE 15'
31 47345 GUMP HOSE, SCREW TYPE 1
31A 47345 CLAMP, FUEL LINE RED 2
32 46704 CAP, GAS 1-1/2-7 THD BLK 1
33 325547 OIL DRAIN 1
33A, 47828 CAP, PIPE 3/89-18 NPT 1
34-, 309092 CONTROL, THROTTLE 1
35 320SS3 SCREW, 10-24X 63PHPNMACRSS 2
36, 271166 NUT, #10-24 HEXKEPS 2
37 57569 WIRE RETAINER 2
38 300508 KNOB, THROTTLE 1
39 159585 SCREW #8-32 X .38 PHPNMA 1
40 120622 NUT, #8-32 REHEX 1
38 56538 RETAINER, WIRE 1
39 35258 SCREW. 10-24X.3B SLHWATAP 1
40 50607 KNOB, ROUND THROTTLE BUCK 1
41 327986 CONTROL.CHOKE 42.25LG PAN TK 1
42 314522 CLIP. CHOKE RETAINER 1
43, 57444 TIE. CABLE BUCK 2
* See Engine Pages,
53
