REPAIR PARTS

12 HP 36" LAWN RIDER - - MODEL NUMBER 917.257462

BRIGGS & STRATTON ENGINE • MODEL NUMBER 283707, TYPE NUMBER 0217-01

Reference Number

909

310

311

510

544

801

802

803

___ Manufacturer

Motor and

Drive AssV.

Thru Bolt

.Assembly

Brush

Assembly

Drive

Assembly

Armature

Assembly

Drive End Cap

Assembly

End Cap Asa'y.

Commutator

Housing

Assembly

Briggs &

Strarflon

Housing

t-enoih

. 12V

394805

94003

395538

. 420421::.

. 3gW37,-

____ 39-4856 _

- 395537-

393825

'Includes #398003 Clutch Assembly (Ref. No. 513)

#280104 Gear

(Ref. No. 783)

#490467 Retainer and Pin (Ref. No. 876)
# 94288 Roll Pin

(Ref. No. 896)
