1. Top cover
18. Light/power switch
2. Bobbin winder tension disc
19. Thread cutter
3. Thread guide
20. Presser foot thumb screw
4. Pressure regulator
21. Presser foot
5. Take-up lever
22. Needle clamp screw
6. Face cover
23. Needle
7. Face cover thread guide
24. Needle plate
8. Top thread tension control
25. Feed dogs
9. Guide pin
26. Shuttle cover
10. Extension table -
27, Hand wheel
11
. Support leg
28. Clutch knob
12. Guide pin
29. Nomenclature plate
13. Spool pins
30. Electric cord receptacle
14. Bobbin winder
31. Presser foot lever
15. Stitch selector
32. Foot control
16. Reverse stitch lever
33. Accessory box
17. Stitch length dial
34. Owner's manual
