PARTS LIST FOR CRAFTSMAN 18-INCH MOTORIZED SCROLL SAW
MODEL NO. 113.207600 AND 113.207650
Always order by Part Number - Not by Key Number
FIOURE 1
Mo. Pari
No.
Description Key
No,
Part
No.
Description
1 STD601105 'Screw, Pan Cross Type “T” 35 STD551210 'Lockwasher, External No 10
10-32 X 1/2 36 66025 Rod, Tension
2 66015 Cover, Motor 37 66030 Wedge, Rip Fence
3 66016 Fan 38 66033 Insert Assembly
4 66005 Motor 39 STD551206 'Lockwasher, Internal No 6
5 66032 Housing Assembly 40 60459 Screw, Fit Hd Type "T”
6 60464 Qr'sor'fbt" ^3 L# t---. 3
10-32
X
1 3/8
7 STD551010 ‘Washer, 13/64 x 7/16 41 STD600603 'Screw, Pan SI Type "T"
Y C\0^ 6-32 X 5/16
8 66021 Knob 42 66022 Panel, Trim
9 66034 Tube Assembly, Upper 43 ^ 62176 Knob, Miter Gauge
10 66024 Retainer 44 60526 Bolt, Carriage 1/4-20 x 2-1/2
11 66009 Cap 45 805116 Bumper, Rubber
12 66019 Holder, Blade 46 STD551126 ‘Lockwasher, 1/4
13 60527 Screw, Hex Soc Half Dog 47 STD541025 'Nut, Hex 1/4-20
Set 10-32 X 1/4 48 60465 Washer, 21/64 x 4 7 / 6 4 x 1/16
14 66011 Clip, Blade 49 63387 Knob
15 tBIade. Scroll Saw 50 66012 Clip, Trunnion
16 66029 Wedge, Blade Tension 51 66006 Base
17 66010 Channel, V 52 66026 Scale, Bevel
18 66007 Bearing, Flanged 53 66008 Bracket, Trunnion
19 STD541408 'Nut, Hex Locking 8-32 54 STD533107 'Bolt, Carriage 5/16-18 x 3/4
20 66014 Counterbalance 55 STD551225 'Lockwasher, External 1/4
21 STD551012 ‘Washer, 17/64 x 1/2 x 1/32 56 STD522503 ‘Screw, Hex Hd., 1/4-20 x 3/8
22 STD551231 'Lockwasher, Internal 5/16 57 60463 Spacer
23 60460 Screw, Shoulder 5/16 58 66023 Pump
24 66018 Guard, Blade 59 66028 Tubing
25 809102~2 Knob 60 27733 Nut. 5/16
26 60129 Washer, 21/64 x 1/2 x 1/32 61 66027 Spring
27 60461 Screw, Hex Cap 5/16-18 x 2 62 STD502502 'Screw, Set 1/4-20 x 1/4
28 66036 Link Assembly 63 37818 Relief, Strain
29 60467 Ring, Retaining 64 66013 Cord with Plug
30 60466 Washer, ,190 x 88 x .040 65 803709 Connector, Wire
31 66035 Tube Assembly Lower 66 62170 Gauge Assembly, Miter
32 62442 Switch, Locking 67 66020 Key. Blade Holder
33 60256 Key, Switch 68 37836 Wrench, Hex L 3/32
34 ST0601103 ‘Screw, Pan Cross Type “T" 66017 Owner's Manual (Not
10-32
X
5/16 Illustrated)
66031 Bag of Loose Parts (Not
Illustrated)
’Standard hardware items - may be purchased locally
t Stock item - May be secured through the Hardware Dept-
of most Sears Retail Stores or Catalog Order Houses
