ACC ELECTRIC HEATER
AND CONTROLS
LOW-VOLTAGE
TERMINAL AREA i|
FAN DECK WIRING-^^
PASSAGE HOLE
(HIDDEN)
OUTDOOR
CABLE
ENTRY HOLE
INTERFACE BOX
REFRIGERANT LINE
CONNECTIONS
SEV ASSEMBLY'
CONDENSATE
DRAINS
MOTOR LEADS
ECM MOTOR
CONTROLLER
BLOWER ASSEMBLY
INDOOR COIL
FILTER SECTION
Fig. 11—40QV024 Fan Coil
OUTDOOR
CABLE
ENTRY HOLE
MOTOR LEADS
1^'
ECM MOTOR
CONTROLLER
REFRIGERANT
LINE CONNECTIONS
SEV ASSEMBLY
CONDENSATE
DRAINS
ACC. ELECTRIC
HEATER AND CONTROLS
jr LOW-VOLTAGE
TERMINAL AREA
FAN DECK WIRING
PASSAGE HOLE
INTERFACE BOX
BLOWER
ASSEMBLY
INDOOR COIL
FILTER SECTION
Fig. 12—40QV036 Fan Coil
R
A87445
A87446
