YSI Incorporated Displays and Loggers 11
(1) The Setup Header menu allows
you to specify control and timing
information for the deployment. Be
sure to set a file name and an interval.
We recommend that warm-up time be
set between 40 and 60 seconds.
(2) The Setup Filter menu allows
you to automatically discard samples
that do not meet your criteria. This
feature is rarely used.
(3) The Start YSI 610 Logging menu begins the logging session that was specified in the
Setup Header and Setup Filter menus. If the file name specified already exists and was
created by Logging on the YSI 610, new data will be appended to the file. If the file
name does not exist, you will be asked if you want to create it, asked to enter a site name,
and asked if you want to enter the weather info. Pressing the Esc or Power keys
terminates logging. Logging stores all parameters to the data file even though only 12 fit
on the screen.
If the sonde is equipped with a wiping turbidity probe, the probe will be cleaned
automatically before each sample but only if time permits. Cleaning takes up to 24
seconds, and the YSI 610-DM makes sure that cleaning will end at least 30 seconds
before the sample. You set the number of wipes in the Sonde main menu, see 2.9,
Sonde menu of the YSI 6-Series Operations Manual. When the YSI 610 is started, the
number of wipes is included in the Logging screen. This allows you to verify that wiping
will occur.
LOG
Setup Header
Setup Filter
Start 610 Logging
Information
LOG
Site: ysprings
StDate: 5/15/96
StTime: 21:00:00
Duration: 24hrs
Interval: 30min
WarmupTime: 40
File: downstr7
shft
Warmup Time allows
DO probe to stablize.
Time is in seconds.
Enter filename and site.
Start date and time may
be typed in as “now”.
LOG
Setup Header
Setup Filter
Start 610 Logging
Information
LOG
38
Logging...
Warmup Time: 40
Interval: 24hrs
Duration: 30min
Countdown in seconds
to first logged reading.
LOG
Setup Header
Setup Filter
Start 610 Logging
Information
LOG
TMP 20.54
CND 0.687
DO% 97.5
DOc
38.0
pH 8.32
NO3 2.35
SpC 0.750
SAL 1.42
DO 8.56
DEP 10.12
ORP 90.2
TRB
2.3
12:30:00 SAMPLE
Flashes on momentarily
when readings are stored.
