ERROR / FAILURE CODES ON LCD
ERROR
CODE
ERROR
DESCRIPTION ICON
BEEP ALARM
01 Bus failure detected when starting
Continuous Beep
02 Hi BUS Voltage
03 Low BUS Voltage
04 Bus Unbalanced
06 Converter Over Current
11 Inverter soft start failure
12 Inverter HI voltage
13 Inverter LOW voltage.
14 Inverter L1 output short-circuit SHORT
15 Inverter L2 output short-circuit SHORT
17 L1-L2 Inverter output (line to line) short circuit detected. SHORT
1A L1 Negative Voltage failure
1B L2 Negative Voltage failure
21 Battery SCR Short-Circuit
24 Inverter Relay Short-Circuit
29 Battery fuse broken in battery mode
31 Failure detected in parallel communication
36 Parallel output unbalanced
41 HIGH Temperature.
43 UPS Overload: High power consumption in Watts at UPS
output. OVERLOAD
46 Not Recognized UPS model. Check jumper configuration in
CRTL board.
ALARM
CODES ON LCD
WARNING
CODE
WARNING
DESCRIPTION
01 Battery unconnected
02 IP Neutral loss or IP L2 fuse broken
07 Battery over charge
08 Low battery
09 Overload
0A Fan failure
0B EPO enable
0D Over temperature
0E Charger failure
10 L1 IP fuse broken
11 L2 IP fuse broken
21 Different Line setting in parallel UPS
22 Different Bypass setting in parallel UPS
24 Different configuration for Inverter output in parallel UPS
25 Different configuration for frequency in parallel UPS
27 Different configuration for L1 and L2 in parallel UPS
28 Different configuration for phase angle in parallel UPS
33 Locked in bypass after overload 3 times in 30min
34 Converter current unbalance
35 Battery fuse broken
36 Inverter inter-current unbalance
39 Input phase error
3A Cover of maintain switch is open
3C Utility extremely unbalanced
