User Manual
- UPS ONLINE 6K/10K 2Ph
ENGLISH
_____________________________________________________________________________________________________________________
20140714_ 6K-10K 2PH (EN)
- 36
11.-
UPS
CONFIGUIRATION
* This menu is activated by simultaneous selection of “Test/Up” + “Mute/Down” keys during 1 second or longer when UPS
is in OFF or BYPASS mode.
Configurable functions according to UPS mode
Code Description
Bypass
AC ECO CVCF
Battery
Battery
mode mode mode mode mode Test
1 Output
voltage
●
2 Output
frequency
●
3 Output
Phase
●
4
Output parallel function setting
●
5
Voltage range for bypass
●
6
Frequency range for bypass
●
7
ECO mode enable/disable
●
8
Voltage range for ECO mode
●
9
ECO mode frequency range
setting
●
10
Bypass mode setting
●
●
11
Battery backup time setting
●
●
●
●
●
●
12
Reserved /Neutral Loss**
●
13
Battery voltage adjustment
●
●
●
●
●
●
14
Charger voltage adjustment
●
●
●
●
●
●
15 Inverter1
voltage
adjustment
●
●
●
16 Inverter2
voltage
adjustment
●
●
●
”●” configurable parameter according to each UPS working mode.
