30 Part No. 057-086 3000 Series OPERATING MANUAL ISSUE 4 03/12/2009 ADM
CONFIGURATION PARAMETERS – OUTPUTS (Page 4)
401 Digital output 1 source
402 Digital output 1 polarity
403 Digital output 2 source
404 Digital output 2 polarity
405 Digital output 3 source
406 Digital output 3 polarity
407 Digital output 4 source
408 Digital output 4 polarity
CONFIGURATION PARAMETERS – TIMERS (Page 5)
501 Remote Start Delay 0:00
502 Preheat timer 0:00
503 RESERVED Crank time 0:00
504 RESERVED Crank rest time 0:00
505 Smoke limiting 0:00
506 Smoke limiting off 0:00
507 RESERVED Safety On Delay 0:00
508 Warm up time 0:00
509 Return Delay 0:00
510 Cooling Time 0:00
511 ETS Solenoid Hold 0:00
512 RESERVED Failed to stop delay 0:00
513 RESERVED Generator transient delay 0.0
514 RESERVED Low power shutdown delay 0:00
515 Breaker trip pulse 0:00
516 Breaker close pulse 0:00
CONFIGURATION PARAMETERS – GENERATOR (Page 6)
601 Alternator Fitted On (1), Off (0)
602 Alternator Poles 0
603 RESERVED Generator fail to close delay 0:00
604 RESERVED Generator fail to close delay 0:00
605 Under Voltage trip enabled On (1), Off (0)
606 Under Voltage trip level 0 V
607 Loading Voltage 0 V
608 Over Voltage trip level 0 V
609 Under frequency trip enable On (1), Off (0)
610 Under frequency trip level 0.0 Hz
611 Loading Frequency 0.0 Hz
612 Nominal Frequency 0.0 Hz
613 Over frequency trip enable On (1), Off (0)
614 Over Frequency trip level 0.0 Hz
615 AC System Selection List
