66
4. Using a 3/16” Allen wrench, loosen the 1/4”-20 socket head on tweeter
assembly (see Figure 17 below).
5. Slide the tweeter until the lock down bolt is centered above the alignment
mark on the tweeter mounting bracket.
6. Retighten the socket head capscrews until snug.
Note: When loosening or tightening the screws, be careful that you do not
damage the painted finish.
P h a s e D e l a y C o r r e c t i o n - C e i l i n g o r O t h e r C u s t o m L o c a t i o n
Because of the large number of unique combinations for your location, we
are unable to provide the exact alignment setting for you. If you have followed the
instructions closely up to this point, you will be able to set the PDC by experiment.
This is done as follows:
• Unhook all the speakers except the Center Channel.
• Using a 3/16” Allen wrench, loosen the 1/4”-20 socket head bolts that
hold the tweeter in place.
• Play a sound track that has female vocal.
• Sit in your listening location and have someone slowly slide the tweet-
er forward and backwards. Listen for the location that the female
vocal is free from any chest or nasal sound. The vocals will be clean
