1. Insert either the short or the long threaded bolt, depending on the
desired height (see Figure 6) as far as it will go into the hole in the bot-
tom of the Center channel. Make sure the Allen key end is accessible.
2. If required, place the corresponding number of spacer discs over the bolt.
3. Screw the acoustical diode onto the bolt until it is roughly half way into
the diode.
4. Screw the spike (with nut) all the way in until it just touches the bolt. Do
not tighten the nut at this time.
5. Repeat steps 1 through 4 with the other spikes.
S e c t i o n 4 . 1 - M e a s u r e d L i s t e n i n g P o s i t i o n
Pulse alignment accuracy of the Center channel has been established and
verified at Wilson Audio’s R&D laboratory. The tables used in this section are a
result of this testing.
R o o m S e t u p
The Center channel allows for different listening distances (away from the
speakers) and listening ear heights (measured distances from the floor up to your
ear). See Figure 7 below. For each distance/ear height combination, there is a
unique alignment geometry. To make correct in-home setup of the Center channel
possible without test equipment, Wilson Audio has measured the correct geometric
