Wilkerson V28 User Manual
Warning, Avertissement
INSTALLATION
1. Refer to WARNING prior to installation.
2. Install as close to the point of use as possible.
3. Unit must be installed with the flow in the direction of the flow arrow on
top of the body.
4. Avoid using reducing bushings, couplings, etc., whenever possible to install
this product. These devices restrict air flow and can affect performance.
5. Maximum pressure rating is 150 psig (10.3 bar). Temperature range is
32°F to 150°F (0°C to 65.5°C).
6. Unit can be locked in the closed position using a standard padlock.
E N G L I S H
Installation & Service Instructions
84-012-000
Safety Lockout Valve
Models V18 and V28
ISSUED: February, 2005
Supersedes: April, 2002
Doc. #84-012-000, Rev. 2
WARNING
To avoid unpredictable system behavior that can cause personal injury
and property damage:
•
Disconnect electrical supply (when necessary) before installation,
servicing, or conversion.
•
Disconnect air supply and depressurize all air lines connected to
this product before installation, servicing, or conversion.
•
Operate within the manufacturer’s specified pressure, temperature,
and other conditions listed in these instructions.
•
Medium must be moisture-free if ambient temperature is below
freezing.
•
Service according to procedures listed in these instructions.
•
Installation, service, and conversion of these products must be
performed by knowledgeable personnel who understand how
pneumatic products are to be applied.
•
After installation, servicing, or conversion, air and electrical supplies
(when necessary) should be connected and the product tested for
proper function and leakage. If audible leakage is present, or the
product does not operate properly, do not put into use.
•
Warnings and specifications on the product should not be covered
by paint, etc. If masking is not possible, contact your local
representative for replacement labels.
!
WARNING
FAILURE OR IMPROPER SELECTION OR IMPROPER USE OF THE
PRODUCTS AND/OR SYSTEMS DESCRIBED HEREIN OR RELATED
ITEMS CAN CAUSE DEATH, PERSONAL INJURY AND PROPERTY
DAMAGE.
This document and other information from The Company, its subsidiaries
and authorized distributors provide product and/or system options for further
investigation by users having technical expertise. It is important that you
analyze all aspects of your application, including consequences of any
failure and review the information concerning the product or systems in the
current product catalog. Due to the variety of operating conditions and
applications for these products or systems, the user, through its own
analysis and testing, is solely responsible for making the final selection of
the products and systems and assuring that all performance, safety and
warning requirements of the application are met.
The products described herein, including without limitation, product features,
specifications, designs, availability and pricing, are subject to change by
The Company and its subsidiaries at any time without notice.
EXTRA COPIES OF THESE INSTRUCTIONS ARE AVAILABLE FOR
INCLUSION IN EQUIPMENT / MAINTENANCE MANUALS THAT UTILIZE
THESE PRODUCTS. CONTACT YOUR LOCAL REPRESENTATIVE.
!
F R E N C H
AVERTISSEMENT
Afin d’éviter un fonctionnement imprévu du système pouvant
occasionner des blessures aux personnes et des dommages matériels :
•
Débrancher l’alimentation électrique (si nécessaire) avant toute
installation, entretien ou conversion.
•
Débrancher l’alimentation en air et dépressuriser toutes les
canalisations d’air connectées à cet appareil avant installation,
entretien ou conversion.
•
Utiliser l’appareil conformément aux normes de pression,
température, et autres conditions spécifiées par le fabricant dans
ces instructions.
•
Le médium doit être exempt d’humidité si la température descend
en dessous de 0°C.
•
L’entretien doit se faire conformément aux procédures décrites ici.
•
L’installation, l’entretien, et la conversion de ces appareils doivent
être effectués par des personnels qualifiés, au fait des techniques
pneumatiques.
•
Après installation, entretien, ou conversion, les alimentations en
air et en électricité (si nécessaire) seront connectées et l’appareil
testé pour vérifier son fonctionnement correct et l’absence de
fuites. Si l’appareil présente une fuite audible ou ne fonctionne
pas correctement, ne pas l’utiliser.
•
Les inscriptions concernant les avertissements et spécifications
sur l’appareil ne devront pas être recouvertes de peinture, etc. Si
le masquage est impossible, contactez votre représentant local
pour des étiquettes de remplacement.
!
Richland, MI 49083
Tel: (269) 629-5000
FICHE D’INSTALLATION ET D’ENTRETIEN
Vannes d’isolement de sécurité modèles V18 et V28
MAINTENANCE
THE UNIT MUST BE REMOVED FROM THE COMPRESSED AIR LINE.
1. Remove retaining screws, and separate body halves.
2. Remove shut off blade.
3. Remove O-rings from body halves.
4. Lightly lubricate O-rings and place in grooves on body halves.
5. Align shut off blade on pivot pin located on outlet body half as shown.
6. Place body halves together and tighten screws to approximately 20 in/lbs.
ACCESSORIES
Plastic Slide and O-rings:
V18 ....................................................................................... VRP-96-925
V28 ....................................................................................... VRP-96-926
